Overview
The Allen-Bradley 20-750-2262D-2R is an I/O option kit designed for use with PowerFlex 753 and 755 series drives, providing 6 digital inputs, 2 analog inputs, 2 analog outputs, and 2 relay outputs. With a 115 VAC rating, this module supports integration of multiple device types into industrial motor control systems. The 20-750-2262D-2R is part of the PowerFlex 22-series I/O option kits manufactured by Rockwell Automation under the Allen-Bradley brand.
Key Features
- Provides 6 digital inputs, 2 analog inputs, 2 analog outputs, and 2 relay outputs
- Analog channels can be set for current or voltage operation, while digital inputs support 24 VDC or 120 VAC control signals
- Designed to enhance PowerFlex 753, 755, 755TR, 755TL, and 755TS drives by adding configurable analog, digital, and relay connections
- Compatible with Ethernet/IP networks with Port 7 as the designated valid port for connectivity
- Allows host drives to expand their connectivity range, enabling integration into larger, more complex automation and motor control applications
Technical Specifications
- Input Voltage: 115 VAC IO
- Digital Inputs: 6
- Analog Inputs: 2
- Analog Outputs: 2
- Relay Outputs: 2
- Module Type: 22-series I/O module
- Mounting: Port 7
- Operating Temperature: -25°C to +55°C (-13°F to +131°F)
- Storage Temperature: -40 to 70 degrees Celsius
- Weight: 0.45 lbs
- Environmental: Suitable for clean, non-corrosive atmospheres with maximum relative humidity of 80% without condensation
- Product Type: Option Module
- Manufacturer: Rockwell Automation (Allen-Bradley)
Typical Applications
This 115 VAC module supports integration of multiple device types into industrial motor control systems. Ideal for users needing enhanced I/O functionality for PowerFlex drives, suitable for applications across manufacturing, motion control, process automation, and other industrial sectors. The module’s configurable analog and digital channels enable flexible system expansion for process monitoring, feedback signals, and relay-based device control.
Compatibility & Replacements
Designed to enhance PowerFlex 753, 755, 755TR, 755TL, and 755TS drives by adding configurable analog, digital, and relay connections. Not compatible with PowerFlex 755TS drives in CIP motion mode. This 22-series I/O option module installs via Port 7 on compatible PowerFlex 750-series drives. Direct replacement modules with identical part number 20-750-2262D-2R ensure seamless substitution in existing systems. Installation requires secure attachment to the host drive and configuration through drive software or associated commissioning tools.
