Overview
The Allen-Bradley 1790-T16BV0X is a CompactBlock LDX expansion module engineered for DeviceNet-based automation systems. This 16-point digital input expansion block extends input capacity in control architectures without requiring system redesign. With universal input compatibility and reliable 24VDC signal processing, the 1790-T16BV0X integrates seamlessly into CompactBlock LDX base stations and supports scalable industrial I/O configurations.
Key Features
- 16 universal digital input points with sink/source compatibility
- 24VDC nominal operating voltage with 2 ms response time
- Built-in DeviceNet network connectivity for real-time I/O communication
- Screw-clamp terminal connections for secure industrial wiring
- IP20 enclosure rating suitable for in-cabinet mounting
- DIN rail and panel-mount capability for flexible installation
Technical Specifications
- Input Points: 16 universal digital inputs
- Voltage: 24 VDC nominal
- Input Current: 8 mA per module
- Response Time: 2 ms
- Terminal Type: Screw-clamp connectors
- Mounting: DIN rail or panel-mount
- Enclosure Rating: IP20
- Network: DeviceNet
- Certifications: UL, CE, C-TICK, CUL, KC
Typical Applications
- Factory automation and manufacturing process control
- Discrete part handling and sorting systems
- Packaging machinery requiring distributed I/O
- Material handling conveyors and transfer systems
- Machine tool control and monitoring
- Industrial equipment retrofits with legacy CompactBlock systems
Compatibility & Replacements
Compatible With
- All CompactBlock LDX base blocks and modules
- DeviceNet-based control networks
- Rockwell Automation control systems supporting DeviceNet
- DIN-rail and panel-mounted industrial control cabinets
Replaces / Drop-In Replacement For
The 1790-T16BV0X is a legacy CompactBlock LDX module. Verify compatibility with your system integrator before ordering replacements for discontinued I/O expansion blocks.
Works With
- DeviceNet communication protocol
- Rockwell Automation Studio 5000 (with DeviceNet gateway configuration)
- CompactBlock LDX modular architecture
- 24VDC industrial power supplies
