Overview
The Allen-Bradley 1492-CABLE025RTBB is a factory-assembled prewired digital I/O cable engineered for industrial automation systems. It simplifies connections between PLC output modules and IFM (Interface Module) terminal blocks, featuring a 25-pin D-shell right-angle connector and providing a plug-and-play solution for reducing wiring errors and installation time.
Key Features
- 25-pin D-shell right-angle connector configuration for compact panel mounting
- Prewired and pretested for reliable, error-free installation
- 2.5-meter (8.2 ft) cable length for flexible system layout
- Compatible with modular I/O modules for Bulletin 1756 ControlLogix, 1769 CompactLogix, 1746 SLC 500, and 1771 PLC-5
- Reduces installation time and panel wiring complexity
- Industrial-grade construction for harsh control environments
Technical Specifications
- Cable Length: 2.5 meters (8.2 feet)
- Connector Type: 25-pin D-shell
- Connector Orientation: Right angle
- Application: Digital I/O module connections
- Certifications: CE, CSA, CUL, UL
- Manufacturer: Rockwell Automation / Allen-Bradley
Typical Applications
The 1492-CABLE025RTBB is ideal for:
- PLC I/O module interconnections in ControlLogix and CompactLogix systems
- SLC 500 and PLC-5 legacy system upgrades
- Control panel wiring simplification
- System integrator projects requiring plug-and-play connectivity
- Industrial equipment automation and machine control
Compatibility & Replacements
The Bulletin 1492 wiring system is compatible with modular I/O modules for Bulletin 1756 ControlLogix, 1769 CompactLogix, 1746 SLC 500, and 1771 PLC-5 platforms. The 1492-CABLE025RTBB provides a direct, plug-and-play interface for 1492 IFM terminal block modules. Verify connector and pin count compatibility with your specific PLC I/O module before ordering.
