Overview
The Allen-Bradley 1492-AIFM8-F-5 is a fusible analog interface module (AIFM) that simplifies field-side wiring for analog sensor and actuator circuits. With 8 channels, 24V DC blown fuse indicators, and a D-shell cable connector, this module is engineered for demanding industrial automation applications requiring reliable signal termination and diagnostics.
Key Features
- 8 analog I/O channels (configurable as input or output)
- Fusible design with 24V DC blown fuse indicators for rapid fault detection
- 5 terminals per input connection for organized wiring
- D-shell cable connector for secure industrial-grade connections
- DIN rail mounting for compact panel integration
- Rated for 10–30V DC operation, 2 A per circuit, 12 A maximum module current
Technical Specifications
- Catalog Number: 1492-AIFM8-F-5
- Channels: 8
- Rated Operational Voltage: 10–30V DC
- Rated Current (per Circuit): 2 A
- Rated Current (Module Max): 12 A
- Terminals per Input: 5
- Connector Type: D-shell
- Mounting: DIN rail
- Operating Temperature: 0°C to +60°C
- Dimensions (H × W × D): 83.06 mm × 119.89 mm × 69.6 mm
- Fuse Indicators: 24V DC blown fuse indicators
- Certifications: UL, CE, C-TICK, CCC
Typical Applications
- Analog sensor interface wiring in PLC/PAC systems
- Process control signal termination (4–20 mA loops, 0–10V signals)
- Distributed I/O systems with remote analog modules
- Temperature and pressure transmitter connections
- Motor speed and load monitoring circuits
Compatibility & Replacements
The 1492-AIFM8-F-5 is compatible with Allen-Bradley CompactLogix, ControlLogix, and MicroLogix analog I/O modules using the standard wiring configurations outlined in the 1492 series technical documentation. This module is a direct fit for applications originally specified with fusible 8-channel analog interface modules and serves as a drop-in replacement for equivalent legacy models in industrial control systems. Verify terminal block configuration and connector type against your original module to ensure seamless integration.
