Overview
The Allen-Bradley 140M-C-PEC23 is a 25-amp ECO connecting module designed for seamless integration with Bulletin 140M motor protection circuit breakers and 100-C series contactors. This connecting bridge provides both electrical and mechanical interconnection in a compact single DIN rail mounting design. The module is optimized for AC and DC electronic coils and is part of the industry-standard 140M accessory family for motor control and protection applications.
Key Features
- 25-amp rated connecting module for 140M-C to 100-C09–C23 compatibility
- ECO design for single DIN rail mounting with integrated electrical and mechanical interconnection
- Supports both AC and DC electronic coils in contactors
- UL, CSA, CE, CUL, and KC certified for industrial safety compliance
- Compact connecting bridge eliminates need for external wiring harnesses
Technical Specifications
- Amperage: 25 A
- Type: ECO Connecting Bridge Module
- Compatible 140M Frame: C
- Compatible 100-C Range: 100-C09 through C23
- Coil Type Support: AC and DC electronic coils
- Mounting: Single DIN Rail
- Certifications: UL, CSA (CUL), CE, CCC, KC
- Weight: 0.06 lb
- UPC: 611320090383
Typical Applications
- Motor control and protection in industrial automation systems
- ECO starter assemblies combining 140M MPCB with 100-C contactors
- Type E self-protected combination motor controller applications
- OEM machine builders and plant integrators requiring compact motor control solutions
- Maintenance and retrofit upgrades for existing motor circuits
Compatibility & Replacements
Compatible With
- Bulletin 140M Motor Protection Circuit Breakers (MPCB), C-frame sizes
- Bulletin 100-C series contactors, 100-C09 through C23 ratings
- AC and DC electronic coil configurations in 100-C contactors
- IEC combination starter assemblies (103T/107T) as interconnection bridge
- DIN rail mounting systems per IEC 60715 standard
Replaces / Drop-In Replacement For
- 140M-C-PEC23 (current revision)
- 140M-C-PEC23A (alternate connecting module for AC coil applications)
Works With
- Bulletin 140M motor protection accessories ecosystem
- Rockwell Automation Studio 5000 and FactoryTalk integration (via control logic)
- Manual motor controllers and self-protected combination motor controller configurations
- Group Installation and Tap Conductor Protection rated systems per NEC/CEC
- IEC motor control frameworks and eco-starter platforms
