Overview
The Advanced Illumination LL2912 is a precision LED line light engineered for machine vision and line-scan camera applications. This 3″ compact illuminator delivers 75mm of intense, uniform light output across the full length of the lens, making it ideal for high-speed inspection, dimensional measurement, and quality control tasks. The LL2912 is a proven, legacy model within Advanced Illumination’s line light portfolio and continues to serve industrial vision applications worldwide.
Key Features
- Compact 3″ (75mm) form factor with intense line illumination
- Optimized for line-scan camera integration and continuous operation
- Multiple lens options available for varied working distances and line widths
- Available in multiple LED wavelengths for different material and surface characteristics
- 12V and 24V operation supported
- Proven reliability in industrial manufacturing and quality control environments
Technical Specifications
- Illuminated Length: 75mm (3″)
- Operating Voltages: 12V and 24V DC
- Product Type: LED Line Light
- Primary Application: Line-scan camera illumination
- Available Wavelengths: UV (395nm), visible spectrum, and infrared (880nm)
- Lens Variations: Multiple working distance and line width options
- Form Factor: Compact linear array
Typical Applications
- Label and print inspection on high-speed production lines
- Dimensional measurement and edge detection with line-scan cameras
- Barcode and OCR verification in packaging automation
- Surface defect and blemish detection on flat materials
- Web and film inspection systems
- Pharmaceutical and food industry quality control
Compatibility & Replacements
Compatible With
- Line-scan camera systems (all major vendors)
- Machine vision software platforms (Cognex, National Instruments, Basler, etc.)
- Standard industrial 12V and 24V DC power supplies
- Custom machine vision lighting controllers
Replaces / Drop-In Replacement For
- Direct replacement for existing LL2912 fixtures
- Verify compatibility with your specific line-scan camera and lighting controller before ordering
Works With
- All standard line-scan camera interfaces (Ethernet, Camera Link, USB3)
- Analog and digital lighting controllers
- Advanced Illumination driver and strobe modules
- Custom integration with existing machine vision systems
