Overview
The ABB DSQC-236T (model YB560103-CE/26) is a servo axis drive unit engineered to control a single axis of an ABB servo motor (orange series) in ABB industrial robot systems. This circuit board serves as a critical component in the S3 controller architecture, enabling precise motion control for robotic applications including pick-and-place, assembly, and welding operations. The board is mounted within ABB robot control cabinets and works seamlessly with ABB IRB robot platforms.
Key Features
- Single-axis servo motor control optimized for ABB orange-series motors
- Compatible with ABB S3 controller systems and IRB industrial robot platforms
- Robust PCB design for reliable operation in demanding industrial environments
- Drop-in replacement for failed or aging drive boards in existing robot installations
- Proven reliability in ABB robot models including IRB 640, 840, 1400, and 4400/6400 series
Technical Specifications
This servo drive unit board provides direct control over single-axis motion within ABB robotic systems. The DSQC-236T maintains compatibility with the ABB S3 controller generation and integrates with standard ABB cabinet installations for orange-series servo motors. Operating conditions and electrical parameters are optimized for continuous industrial operation in factory environments.
Typical Applications
The ABB DSQC-236T drive unit is widely used in:
- ABB industrial robot motion control (IRB 640, 840, 1400, 4400/6400 platforms)
- Pick-and-place and small-part assembly operations
- Robotic welding and material handling applications
- Precision manufacturing and automated production lines
- Robot axis replacement and system refurbishment projects
Compatibility & Replacements
The DSQC-236T (YB560103-CE/26) is designed as a direct replacement for worn or defective servo drive boards in ABB S3-based robot systems. Variants of this board include YB560103-CE/23, YB560103-CE/24, and YB560103-CE/28 depending on controller revision and application requirements. Always verify your specific ABB robot model and controller version before ordering replacement boards. This unit is compatible with ABB servo motors in the orange series and integrates with cabinet-mounted ABB S3 control architectures.
[{“label”: “Manufacturer”, “value”: “ABB”}, {“label”: “Model Number”, “value”: “DSQC-236T / YB560103-CE/26”}, {“label”: “Product Type”, “value”: “Servo Axis Drive Unit (Circuit Board)”}, {“label”: “Axis Configuration”, “value”: “Single Axis”}, {“label”: “Motor Series”, “value”: “ABB Orange Series Servo Motors”}, {“label”: “Controller Compatibility”, “value”: “ABB S3 Controller”}, {“label”: “Robot Platform Compatibility”, “value”: “ABB IRB 640, 840, 1400, 4400/6400, and other IRB models”}, {“label”: “Mounting”, “value”: “Cabinet-mounted PCB”}, {“label”: “Condition”, “value”: “Used”}, {“label”: “Warranty”, “value”: “12 months”}]
