Overview
The ABB AL16-30-01 magnetic contactor (1SBL183001R8101) is a low-consumption, DC-operated contactor engineered for motor control and industrial automation applications. Featuring a solid-core magnet circuit with minimal coil power draw, this contactor provides efficient switching of 3-phase motors and general-purpose power circuits up to 690V AC or 220V DC. The unit delivers dependable performance in demanding industrial environments with proven IEC and NEMA compliance.
Key Features
- 24V DC coil operation with solid-core magnet circuit for low power consumption
- Rated for 3-phase motor control up to 690V AC or 220V DC switching capacity
- Compact, modular DIN rail mounting design for cabinet integration
- Spring terminal technology for fast, secure front-face connections
- IEC and NEMA standards compliance with clear coil voltage marking
- Supports capacity switching, lighting control, and isolation applications
Technical Specifications
- Model: AL16-30-01 / 1SBL183001R8101
- Coil Voltage: 24V DC
- Magnet Circuit: Solid-core with low consumption coil
- Power Circuits: Up to 690V AC or 220V DC
- Operating Principle: DC-operated magnetic contactor
- Contact Configuration: 3-pole standard (auxiliary contact options available)
- Terminal Technology: Spring terminals or screw terminals
- Approvals: IEC and NEMA standards
- Series: AL16 Low-Consumption DC Contactors
Typical Applications
The AL16-30-01 is ideal for controlling 3-phase induction motors in pumps, compressors, conveyors, and industrial machinery. It is also used for capacitor switching, lighting circuits, and general power isolation in control cabinets. Suitable for facilities automation, motor starters, and motor protection circuits requiring robust DC-operated switching.
Compatibility & Replacements
Compatible With
- ABB contactor auxiliaries and accessory relays (AL-series compatible)
- DIN rail mounting systems in industrial control cabinets
- Spring-terminal and screw-terminal enclosure designs
- IEC and NEMA motor control centers
- 24V DC control circuits in automation systems
Replaces / Drop-In Replacement For
- Verify specific model replacements with your system integrator or ABB technical support before ordering.
Works With
- ABB motor protection and control devices
- ABB auxiliary contact blocks and electronic timers
- Surge suppressors designed for DC-operated contactors
- Standard 24V DC control power supplies and PLC outputs
