Overview
The Allen-Bradley 889D-F5NCDM-5 Series B is a DC Micro (M12) QD cordset designed for secure connections between industrial field devices and control systems. This 889D-F5NCDM-5 cordset features a 5-pin straight female connector with external threads paired with a 5-pin straight male connector with external threads, providing standardized connectivity for proximity sensors, limit switches, photoelectric sensors, and other industrial automation components. With a rated capacity of 4A at 250V and a 5-meter cable length, this cordset delivers the reliability and durability required in demanding manufacturing and process control environments.
Key Features
- 5-pin DC Micro (M12) straight connectors on both ends
- Rated for 4A at 250V operation
- 5-meter (16.4-foot) cable length for extended reach
- PVC cable jacket with unshielded construction
- 22 AWG copper conductor
- Durable overmolded connector design for industrial reliability
- Series B specification compliance
Technical Specifications
The cordset meets standard industrial M12 connector specifications and provides a robust solution for field device interconnection. Cable construction includes PVC jacketing with 22 AWG conductors and unshielded design suitable for general-purpose industrial applications without high electromagnetic interference requirements.
Typical Applications
- Proximity sensor connections
- Limit switch interfaces
- Photoelectric sensor wiring
- AC drive and motor control field device connections
- General industrial sensor networking
- Manufacturing equipment automation
- Process control system integration
Compatibility & Replacements
Compatible With
- Allen-Bradley CompactLogix and ControlLogix PLCs with DC Micro I/O modules
- PROFINET, DeviceNet, and EtherNet/IP networked field devices
- Standard DC Micro (M12) sensor and actuator ecosystems
- Industrial automation control systems using M12 connectivity
Replaces / Drop-In Replacement For
The 889D-F5NCDM-5 directly replaces other 889D Series B 5-pin straight cordsets with equivalent DC Micro M12 connectors. Verify exact connector pin configuration and voltage compatibility with your system integrator before ordering to ensure proper fit and electrical compatibility.
Works With
- Studio 5000 Logix Designer (CompactLogix, ControlLogix)
- Industrial Ethernet networks (EtherNet/IP, PROFINET)
- DC Micro (M12) sensor protocols
- Allen-Bradley distributed I/O architectures
