Overview
The Allen-Bradley 802T-KP is an industrial-grade oiltight plug-in limit switch designed for harsh factory environments. This Series J model delivers reliable snap-action switching for position sensing across material handling, packaging, food processing, and transportation machinery. The 2-pole, 2-circuit configuration with A600 contact rating provides proven durability and long service life in heavy-duty automation control.
Key Features
- Vertical side push roller actuator for positive mechanical actuation
- Plug-in connection type for quick, tool-free installation
- Oiltight metal enclosure rated NEMA, IP67 sealing
- 2-pole, 2-circuit snap-action contact configuration
- A600 contact rating supports high-reliability switching
- Compact 802T form factor suitable for tight installations
Technical Specifications
- Voltage Rating: 600 VAC, 600 VDC
- Current Rating: 10 Amps maximum
- Actuator Type: Vertical side push roller
- Contact Configuration: 2-pole, 2-circuit (snap-action)
- Connection Type: Plug-in with conduit entry
- Enclosure: Metal oiltight
- Operating Temperature: -18 to +110°C (-0 to +230°F)
- NEMA Rating: NEMA 6P / IP67
- Certifications: UL, CSA, CE, KC, CCC
- Shipping Weight: Approximately 0.142 kg (5 oz)
Typical Applications
- Material handling conveyors and sorting systems
- Packaging machinery and filling equipment
- Food processing line position sensing
- Transportation and logistics automation
- Machine end-of-travel detection
- Safety interlocks and emergency stop circuits
Compatibility & Replacements
Compatible With
- Allen-Bradley ControlLogix and CompactLogix PLCs
- Rockwell Automation control systems
- Standard 24VDC to 600VAC industrial control circuits
- Direct PLC input module connections (no additional relay required)
- Conduit and cable-based panel wiring
Replaces / Drop-In Replacement For
- 802T-KP1 (side push horizontal roller variant)
- Similar Allen-Bradley 802T-series plug-in models with 2-circuit configuration
- Verify exact replacement compatibility with your controls engineer before ordering
Works With
- Studio 5000 (for configuration and monitoring)
- Discrete I/O modules on ControlLogix platforms
- Hardwired relay logic and contactor circuits
- Industrial Ethernet and EtherNet/IP gateways (when configured as discrete input)
- All NEMA-compliant control enclosures
