Overview
The Allen-Bradley 22A-D4P0N104 is a PowerFlex 4 adjustable frequency AC drive engineered for compact, reliable motor speed control in industrial automation. Part of the PowerFlex 4 adjustable frequency drive family—one of the most widely used VFD platforms for compact machine-level speed control, this drive delivers dependable performance for applications requiring smooth torque and speed management.
Key Features
- Built-in Sensorless Vector Control for precise speed regulation
- IP20, NEMA/UL Enclosure (open type) with LED display and fixed digital keypad for parameter input
- Reduces machine stress and wear to motors while extending their lives by modifying input voltage and frequency
- Soft start and stop modes with controlled motor acceleration
- Equipped with IGBT brake
- RS485 communication module with LED display and fixed digital keypad interface
Technical Specifications
- Input Voltage Range: 342–528 VAC, three-phase, 50–60 Hz
- Output Voltage: 0–460 VAC, 0–240 Hz
- Output Current: 4.0 A continuous
- Power Rating: 1.5 kW / 2 HP
- Input Current: 5.7 Amps
- Input kVA: 4 kVA
- Control Type: Volts / Hertz or Scalar control
- Enclosure: IP20, NEMA/UL Type Open
- Frame Size: A
- Dimensions: 152 mm (L) × 80 mm (W) × 136 mm (D)
- Communication: DeviceNet, EtherNet/IP, MODBUS, PROFIBUS
Typical Applications
Ideal for controlling small motors in fans, pumps, conveyors, mixers, and general-purpose equipment. Well-suited for speed control of machine tools, fans, pumps and conveyors, and material handling systems. The drive’s compact footprint and cost-effective design make it popular in OEM and end-user applications where space and budget are constraints.
Compatibility & Replacements
Compatible With
- Logix 5000 / Studio 5000 control platforms
- EtherNet/IP, MODBUS, PROFIBUS, and DeviceNet networks
- Three-phase AC motors, 1.5 kW (2 HP) and below
- DIN-rail and panel-mount enclosure systems
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering, as replacement drive models may differ by region and application. Contact technical support for cross-reference information on legacy PowerFlex models.
Works With
- Rockwell Automation Logix control platform for simplified parameter and tag programming
- Allen-Bradley PanelView HMI devices and FactoryTalk software
- RS485 serial communication
- PowerFlex standard programming in RSLogix and Studio 5000
