Overview
The Allen-Bradley 194R-PY is a red/yellow rotary operating handle engineered for use with Bulletin 194R fused and non-fused disconnect switches rated up to 60 amperes. This padlockable disconnect switch handle provides IP66-NEMA type 3R-3-12-4-4X ingress protection and accepts 3 padlocks for secure power disconnection in industrial control applications. The high-visibility color scheme ensures clear identification of the disconnect point, critical for operator safety and emergency response.
Key Features
- Color: Red/Yellow for high visibility
- Padlockable feature allows for up to three padlocks, facilitating compliance with OSHA lockout/tagout (LOTO) requirements
- Ingress Protection: IP66, NEMA 3R, 3, 4, 4X, 12
- Operating Shaft: Compatible with 6 mm (1/4 in.) square shafts
- Standards Compliance: UL 98, CSA C22.2 No. 4, IEC 60947-3
- Certifications: CE Marked, cULus Recognized
Technical Specifications
- Rated Amperage: Up to 60 A
- Padlock Capacity: 3 padlocks in OFF position
- Mounting: Door-mounted
- Material: Durable plastic construction
- Color: Red/Yellow
- Protection Rating: IP66, NEMA 3/3R/4/4X/12
Typical Applications
- Motor control centers and disconnect enclosures
- Industrial machinery disconnecting means
- Panel-mount safety shutoff stations
- Facilities requiring OSHA-compliant lockout/tagout procedures
- Outdoor or washdown environments requiring sealed protection
Compatibility & Replacements
Compatible With
- Bulletin 194R rotary disconnect switches (30 A and 60 A ratings)
- Standard 6 mm (1/4 inch) square operating shafts
- 194R fused disconnect switches
- 194R non-fused disconnect switches
- NEMA 3, 3R, 4, 4X, and 12 enclosure types
Replaces / Drop-In Replacement For
- 194R-HS1
Works With
- OSHA lockout/tagout (LOTO) procedures
- Industrial control systems using Bulletin 194R disconnect switches
- Motor disconnecting means per NEC and IEC standards
