Overview
The Allen-Bradley 1492-XIM120-8R is a relay master and expander interface module engineered for 120VAC industrial automation control systems. This panel-mount module provides eight relay outputs, making it suitable for expanding digital control circuits in PLC systems, motor starters, and industrial control cabinets. The 1492-XIM120-8R operates at 96–132V AC nominal, supporting reliable relay switching for OEM machine builders and system integrators.
Key Features
- 8 independent relay outputs with LED status indicators
- 10/12A per relay with 48A module capacity
- 2 mA indicator circuit current for low-power pilot signals
- Compact DIN-rail mountable form factor: 6.30 x 3.27 x 2.78 inches
- Standard terminal block connections for fast field wiring
- Operates as both master module and expander for system flexibility
Technical Specifications
The module meets IEC standards and is certified for industrial use. Temperature rating spans 0–60°C operating range, suitable for climate-controlled control rooms and moderate industrial environments.
Typical Applications
- Panel-mount relay expansion in automation control systems
- Discrete output switching for motor starters and contactors
- Logic control circuits and permissive interlocking
- Machine safety circuits and e-stop routing
- OEM equipment control cabinets requiring relay output expansion
Compatibility & Replacements
Compatible With
- Allen-Bradley CompactLogix and MicroLogix controllers
- Allen-Bradley SLC 500 systems
- Standard 120VAC control power supplies and pilot signals
- DIN-rail enclosure mounting systems
- IEC-compatible terminal block wiring schemes
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. This module is suitable for applications previously using equivalent Allen-Bradley relay expansion modules in 120VAC circuits.
Works With
- RS Logix 500 and Studio 5000 programming software (discrete output logic)
- Hardwired control circuits and stand-alone pilot signal applications
- IEC terminal blocks and standard industrial wiring practices
- LED indicator troubleshooting and field diagnostics
