Overview
The Allen-Bradley 1485CS-P5N5-M5 is a factory-molded DeviceNet trunk cordset designed for industrial automation and control systems. This 5-meter mini-line cordset combines rugged thick media construction with precision-molded connectors to deliver dependable performance in harsh industrial environments. The prewired assembly eliminates field termination errors and reduces installation time.
Key Features
- 5-meter length with grey PVC thick media for durability and noise rejection
- Mini straight female (trunk end) and mini straight male (device end) connectors
- Factory-molded connectors ensure reliable, repeatable connections
- 5-pole pin configuration for standard DeviceNet applications
- Epoxy-coated zinc hardware resists corrosion in demanding environments
- Pre-assembled design eliminates field termination issues
Technical Specifications
- Cable Length: 5 meters
- Media Type: Thick trunk cable
- Jacket: Grey PVC
- Connector Type (Trunk): Mini straight female, 5-pole
- Connector Type (Device): Mini straight male, 5-pole
- Hardware Finish: Epoxy-coated zinc
- Configuration: Standard passive cable
- Series: 1485 (DeviceNet Media System)
Typical Applications
The 1485CS-P5N5-M5 is commonly deployed in:
- Manufacturing and assembly line automation
- Process control systems using DeviceNet networks
- Material handling and conveyor systems
- Packaging machinery and bottling applications
- Industrial I/O device interconnection on DeviceNet networks
Compatibility & Replacements
Compatible With
- Allen-Bradley DeviceNet scanner modules and gateways
- Devices supporting mini-line DeviceNet connectors (5-pole configuration)
- Industrial networks using DeviceNet thick media topology
- Allen-Bradley CompactLogix, ControlLogix, and SLC 500 systems with DeviceNet modules
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The 1485CS-P5N5-M5 is part of the 1485 family; similar models with different length or connector configurations may be interchangeable depending on application requirements.
Works With
- DeviceNet communication protocol
- Allen-Bradley Studio 5000 (DeviceNet module configuration)
- RSNetWorx for DeviceNet (network design and diagnostics)
- Standard DeviceNet trunk and drop systems
- ODVA (Open DeviceNet Vendor Association) compliant devices
