Overview
The Schneider Electric ZB5AZ009 is a plastic mounting collar (fixing base) engineered for the Harmony XB5 series of 22mm modular pushbuttons and pilot lights. This accessory securely mounts electrical blocks and operators to standard panel cutouts, making it an essential component for industrial control and signaling applications. The ZB5AZ009 delivers reliable performance across diverse industrial environments.
Key Features
- Plastic body construction compatible with Harmony XB5 series 22mm operators
- Snap-fit head design with single-screw tightening for quick, secure mounting
- Modular design enables flexible panel customization and component assembly
- Tested for high vibration resistance with shake-proof terminal connections
- Operates reliably in challenging chemical environments (solvents, oils, detergents)
- Operating temperature range of -25°C to +70°C for versatile deployment
Technical Specifications
- Manufacturer: Schneider Electric / Square-D
- Part Number: ZB5AZ009
- Product Type: Mounting Collar / Fixing Base
- Series: Harmony XB5
- Button Size: 22mm
- Material: Plastic
- Operating Temperature: -25°C to +70°C
- Standards Compliance: IEC, UL, CSA, CCC, EAC, JIS; CE marked
- Packaging: Box of 10 units
- Condition: New in Box
Typical Applications
The ZB5AZ009 mounting collar is ideal for:
- Industrial machinery control panels requiring 22mm pushbutton assemblies
- Manufacturing equipment with modular pushbutton and selector switch installations
- Chemical processing facilities needing robust push-button mounting solutions
- Food and beverage production lines with stringent hygiene requirements
- Heavy-duty machine tool applications with vibration and shock exposure
- NEMA 4/13 and Type 4X enclosures with sealed electrical block assemblies
Compatibility & Replacements
Compatible With
- Harmony XB5 series 22mm modular pushbuttons, selector switches, and pilot lights
- Schneider Electric XB5A operators and electrical block contact assemblies
- Standard industrial control panel cutouts and mounting brackets
- Single and multi-circuit electrical block configurations
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The ZB5AZ009 is a genuine Schneider Electric / Square-D component and the standard mounting base for Harmony XB5 series 22mm operators.
Works With
- Harmony XB4/ZB4 and XB5/ZB5 series pushbutton and selector switch ranges
- Screw clamp, connector, and spring terminal electrical block connections
- IEC 60947-5-4 and IEC 60947-5-5 compliant control and signaling units
- Industrial automation systems using modular control components
