Overview
The Yuken DSG-01-2B2-D24-50 is a solenoid-operated directional control valve engineered for demanding hydraulic applications. This 1/8″ ported valve combines high pressure capability with efficient flow control, making it ideal for industrial machinery, mobile equipment, and automated hydraulic systems. Yuken DSG-01-2B2-D24-50 units feature a robust spool mechanism and wet-type solenoid for reliable, responsive actuation in both industrial and mobile applications.
Key Features
- 2-Position, Spring-Offset Spool Design — Solenoid actuates to one position; spring returns to neutral when de-energized
- High-Pressure, Low-Pressure-Drop Construction — DSG-01 series employs rational flow-channel geometry and powerful wet-type solenoid for efficient operation at elevated pressures
- 24VDC Solenoid — Direct DC voltage actuation with standard industrial voltage compatibility
- ISO 4401-AB-03-4-A (CETOP-3) Mounting — Drop-in compatibility with standard manifold block cavity configurations
- Manual Override Option — Push-pin manual spool changeover for manual system control when needed
Technical Specifications
- Pressure Rating: 31.5 MPa (4,570 PSI)
- Maximum Flow: 63 L/min (16.6 GPM) @ 50 Hz solenoid frequency
- Valve Configuration: 2-position, spring-offset, 4/3 directional control
- Solenoid Voltage: DC 24V
- Mounting Standard: ISO 4401-AB-03-4-A (CETOP-3 / NFPA-D01)
- Port Size: 1/8″ (3 mm) cavity ports
- Spool Type: 2B2 (per Yuken nomenclature)
- Design Number: 50 (installation dimensions remain standard for design numbers 50–59)
Typical Applications
- Directional control in industrial hydraulic presses and injection molding machinery
- Mobile equipment (articulating booms, loaders, cranes) requiring solenoid-actuated directional control
- Automated manifold-based control systems with CETOP cavity ports
- Proportional valve systems using directional spool actuation
- Hydraulic test benches and controlled fluid distribution networks
Compatibility & Replacements
Compatible With
- ISO 4401-AB-03-4-A (CETOP-3 / NFPA-D01) manifold cavities
- Hydraulic systems operating between 31.5 MPa (4,570 PSI) maximum working pressure
- 24VDC power supplies and standard industrial control circuits
- Mineral oil and anti-wear hydraulic fluids (per Yuken specifications)
Replaces / Drop-In Replacement For
- Yuken DSG-01-2B2-D24-70 (same cavity; design number variant)
- Other OEM solenoid directional valves with matching CETOP-3 cavity and 24VDC solenoid
- Verify compatibility with your system integrator or original equipment documentation before substitution
Works With
- Standard 24VDC pilot or main-stage solenoid control circuits
- Manual push-pin override for load-holding or manual changeover operations
- Proportional directional valve systems using spool feedback
- ISO 4401 standard hydraulic manifold systems
