Overview
The Yaskawa SGDV-3R8A11A002000 is a Sigma-5 servopack combining analog voltage or pulse train control with industrial-grade servo amplification. This servopack provides precise speed and position control for demanding automation applications, from machine tools to packaging equipment. The analog interface simplifies system integration while maintaining the advanced motion control capabilities required by modern manufacturing.
Key Features
- Analog voltage and pulse train input control interface
- Sigma-5 servo amplifier architecture for precision motion
- Advanced motion control algorithms including multi-stage notch filtering
- Safety function equivalent to STO (Safe Torque Off) per IEC61800-5-2
- Support for multiple optional modules (Indexer, Safety, DeviceNet communication)
- Compact integrated servopack design saves panel space
Technical Specifications
The SGDV-3R8A11A is configured for analog servo control. For exact input voltage, output current, and power ratings specific to this model suffix variant, verify with Yaskawa technical support or consult the detailed product datasheet.
Typical Applications
- CNC machine tool positioning and spindle control
- Packaging and printing equipment servo drives
- Industrial automation requiring high-accuracy motion
- Systems requiring analog voltage or pulse train input control
- Retrofit and upgrade applications for legacy analog-controlled equipment
Compatibility & Replacements
Compatible With
- Analog voltage control systems (±12V input range)
- Pulse train input control systems
- Optional Yaskawa modules: Indexer, Safety Module, DeviceNet communication
- External encoders and linear scales for high-resolution positioning
- Yaskawa Sigma-5 servo motors (verify specific motor compatibility)
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The SGDV-3R8A11A supersedes certain earlier Sigma-3 and Sigma-4 servopack configurations; consult Yaskawa documentation for specific legacy model cross-reference.
Works With
- SigmaWin+ engineering and tuning software
- DeviceNet fieldbus (with optional module)
- External control systems via analog voltage or pulse train inputs
- Yaskawa motion control tools and diagnostic utilities
