Overview
The Brad Harrison 1R3006A20A120 Woodhead Mini-Change connector is a 3-pin male straight receptacle designed for quick-disconnect cordset applications. This pre-terminated connector assembly includes 12″ of #16 AWG PVC-jacketed cable leads ready for field installation. Engineered for industrial control, instrumentation, and sensor networks, the 1R3006A20A120 delivers reliable push-to-lock connections with minimal downtime.
Key Features
- 3-pin (3P) male straight configuration with internal threads
- 10A current rating at 600VAC/DC
- 12″ pre-terminated cable with #16 AWG conductors
- Secure screw-terminal connection method (#15–#24 AWG compatible)
- Quick-disconnect Mini-Change design for field conversion
- UL and CSA approvals for industrial safety standards
Technical Specifications
Electrical Ratings:
- Current Rating: 10A
- Voltage Rating: 600VAC/DC
- Cable Gauge: #16 AWG
- Conductor Insulation: PVC
- Cable Length: 12 inches
- Pin Configuration: 3-Pin Male Straight
- Thread Type: Internal Threads
- Terminal Type: Screw Terminals
- Cable O.D. Range: 0.20–0.48 inches (5–12 mm)
- Certifications: UL, CSA
Typical Applications
- Industrial machine control and automation systems
- PLC and sensor connectivity networks
- Factory floor equipment interconnects
- Process instrumentation cordsets
- Motor control and power distribution panels
- Field-installable connector assemblies requiring quick disconnects
Compatibility & Replacements
Compatible With
- Woodhead Mini-Change female connectors and receptacles
- Industrial control systems using mini-change quick-disconnect standards
- PLC input/output modules with mini-change connectors
- Standard industrial 600VAC/DC power distribution networks
- Field-attachable cordsets and cable assemblies
Replaces / Drop-In Replacement For
- Original equipment Woodhead 1R3006A20A120 male receptacles
- Equivalent Brad Harrison mini-change male 3P straight connectors
- Legacy industrial cordset assemblies (verify pin configuration before replacement)
Works With
- Woodhead Mini-Change female straight connectors (1A3000-34 series)
- Standard screw-terminal wiring practices (#15–#24 AWG range)
- Industrial enclosure-mount receptacles and panel connectors
- Field conversion kits for quick-disconnect applications
