Overview
The Yaskawa SGDH-02AE is a compact servo drive from the Sigma II series, engineered for precise motion control in industrial automation systems. Rated at 0.2 kW (0.26 HP) with a single-phase 200–230 V AC input, this drive delivers controlled torque and speed regulation suitable for light-load servo applications. The SGDH-02AE operates at frequencies up to 300 Hz and features both pulse and analog input signal compatibility, making it adaptable to diverse control requirements.
Key Features
- Dual Input Modes: Supports both pulse and analog input signals for flexible control integration
- Compact Design: Space-efficient form factor ideal for embedded machine control and retrofit applications
- LED Channel Diagnostics: Real-time status monitoring and troubleshooting visibility via indicator lights
- Configurable Control Modes: Adaptable speed, torque, and position control settings for application-specific tuning
- Wide Frequency Range: 0–300 Hz output frequency supports smooth motor acceleration and deceleration
Technical Specifications
- Rated Output Power: 0.2 kW (0.26 HP)
- Input Supply: Single-phase 200–230 V AC, ±10%, 50/60 Hz
- Input Current: 0.4 A
- Output Current Rating: 3.4 A
- Output Frequency: 0–300 Hz
- Control Method: PWM-controlled sinusoidal output
- Input Signals: Pulse (step/direction) and Analog
- Dimensions: Approximately 40 × 150 × 100 mm
- Series: Sigma II
- Certifications: International standards compliant
Typical Applications
The SGDH-02AE excels in applications requiring compact, reliable servo control:
- Automated positioning and indexing systems
- Light-duty machine actuators and conveyor drives
- Compact CNC spindle or tool changers
- Precision assembly and packaging equipment
- Laboratory and testing machinery with servo motion
Compatibility & Replacements
Compatible With
- Yaskawa SGM rotary and linear servo motors (confirm specific model via datasheet)
- Single-phase 200–230 V AC industrial power systems
- Pulse and analog motion controllers (step/direction or 0–10V analog)
- Standard servo motor encoder types (incremental and absolute encoder compatible)
Replaces / Drop-In Replacement For
- Yaskawa SGDH-02AE-OY (variant with OY connector configuration)
- Other Sigma II compact servo drives in the 0.2 kW class (verify specifications before substitution)
Works With
- Yaskawa Sigma II servo motors (SGM series)
- Standard pulse/direction motion control interfaces
- Analog input control (0–10 V, ±10 V)
- PWM-compatible servo commissioning tools and manual operators
- Encoder feedback systems (incremental and absolute types)
