Overview
The Wittenstein Alpha SK+ 075S-MF2-70-1C1-1S10 is a precision right-angle hypoid gearbox engineered for compact, high-performance mechanical power transmission. This unit combines the axially short design characteristic of the SK+ series with proven servo-grade engineering, making it ideal for applications requiring minimal backlash and reliable torque delivery. The SK+ 075S-MF2-70-1C1-1S10 integrates seamlessly into modern machine tool, robotics, and automation systems where space constraints and precision requirements are critical.
Key Features
- Low-Backlash Hypoid Design: Delivers precision engagement with minimal play, reducing positioning error in servo-driven applications.
- Compact Right-Angle Configuration: Axially short build enables space-efficient machine layouts without sacrificing output torque or efficiency.
- SP+ Compatible Output Geometry: Standardized output interface simplifies integration with motors and load-coupling systems.
- Proven Wittenstein Engineering: Manufactured by WITTENSTEIN alpha GmbH, a leader in precision gearbox design with three decades of servo drive expertise.
- Versatile Application Ready: Suitable for packaging, printing, semiconductor handling, and general industrial automation requiring dynamic precision.
Technical Specifications
The SK+ 075S-MF2-70-1C1-1S10 configuration indicates:
- Series: SK+ (Hypoid Right-Angle Gearbox)
- Frame Size: 075S
- Configuration Code: MF2-70-1C1-1S10
- Gear Ratio: 70:1 (derived from configuration code)
- Output Interface: SP+ Compatible Flange
- Design Type: Right-Angle Hypoid (90° shaft arrangement)
- Condition: Used, Fully Inspected
- Manufacturer: WITTENSTEIN alpha GmbH
Typical Applications
- Servo-driven positioning axes in CNC machine tools
- Robotic arm joint drives requiring low backlash and compact form factors
- Packaging machinery requiring smooth, synchronized multi-axis motion
- Semiconductor equipment handling with precise repeatability
- Industrial automation systems where space efficiency and torque density are paramount
- Dynamic drive applications in printing and converting equipment
Compatibility & Replacements
Compatible With
- WITTENSTEIN alpha servo motor platforms
- Industry-standard servo drives (AC/DC brushless servo controllers)
- Systems using SP+ standard output flange geometry
- Couplings and shrink-disk accessories from WITTENSTEIN alpha accessories line
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The SK+ 075S-MF2-70-1C1-1S10 is a complete model specification; alternative ratios or configurations within the SK+ 075S series may have different performance envelopes.
Works With
- SP+ compatible motor mounting interfaces and output couplings
- WITTENSTEIN alpha modular drive ecosystems and linear actuator platforms
- Standard industrial servo control platforms from Siemens, Beckhoff, Yaskawa, and other major suppliers
- EtherCAT, PROFINET, and other fieldbus-enabled automation networks (via compatible servo drivers)
