Overview
The Westronics CB100246-01 Rev A is an industrial PLC control printed circuit board (PCB) designed for integration into Westronics automation systems. This board serves as a core component in distributed PLC architectures and has been field-proven in manufacturing and process control applications. The board supports modular expansion through compatible Westronics I/O and processor modules.
Key Features
- Industrial-grade PCB design for reliable automation control
- Compatible with Westronics CPU modules and I/O expansion cards
- Supports modular system expansion and reconfiguration
- Proven field reliability in industrial automation environments
- Rev A / MC100246-01 Rev PR2 specification
Technical Specifications
While detailed electrical specifications are not available in current documentation, this board is characterized as an industrial control PCB suitable for 24 VDC logic level systems typical of Westronics automation platforms.
Typical Applications
- Industrial process control systems
- Manufacturing equipment control
- Distributed PLC architectures
- Machine automation and sequencing
- Legacy system integration and replacement
Compatibility & Replacements
Compatible With
- Westronics CB100188-01 CPU module
- Westronics CB100190-01 I/O module
- Westronics CB100190-02 I/O module variant
- Westronics CB100280-01 processor systems
- Other Westronics PLC control systems using standard PCB interconnect
Replaces / Drop-In Replacement For
- CB100246-01 Rev D (alternative revision)
- MC100246-01 Rev PR2 (manufacturer equivalent designation)
Works With
- Westronics modular PLC platform architecture
- Industrial process control software compatible with Westronics systems
- 24 VDC logic level industrial automation environments
- Legacy industrial control integrations
