Overview
The Werma 829.150.55 is a versatile red LED beacon light designed for industrial automation, control panels, and machine signaling applications. This Midi 829 Series unit operates on 24V DC and features three switchable light patterns—continuous, flashing, and rotating—making it ideal for conveying machine status, warnings, or operational alerts on the factory floor. With an energy-efficient design consuming only 300mA, the beacon delivers reliable visual feedback without excessive power draw.
Key Features
- Three Operating Modes: Continuous, flashing, and rotating light patterns selectable for different signaling requirements
- Long Service Life: LED rated to 50,000 hours of operation, minimizing replacement frequency
- Low Power Consumption: 300mA at 24V DC ensures compatibility with standard industrial power supplies
- Durable Construction: Hard-wearing polycarbonate lens is impact-resistant; screw terminals for secure electrical connection
- IP65 Protection: Sealed against dust and low-pressure water jets for reliable operation in harsh environments
- Easy Maintenance: Twist-on/twist-off dome design allows quick bulb and lens service without tools
Technical Specifications
- Supply Voltage: 24 VDC
- Current Draw: 300 mA
- LED Color: Red
- Lens Diameter: 98 mm (Ø)
- Height: 137 mm
- Ingress Protection (IP): IP65
- Lens Material: Polycarbonate
- Operating Temperature Range: −20 °C to +50 °C
- LED Lifespan: Up to 50,000 hours
- Mounting Type: Surface Mount
- Connection: Screw Terminals
- Series: Midi 829
Typical Applications
- Machine status indication (running, stopped, error condition)
- Assembly line and production control signaling
- Warning systems for hazardous operations
- Safety interlocks and emergency alert displays
- Industrial control cabinets and electrical enclosures
- Factory automation and process monitoring
Compatibility & Replacements
Compatible With
- Standard 24V DC industrial power supplies
- Allen-Bradley ControlLogix, CompactLogix, and MicroLogix controllers
- Siemens S7-1200, S7-1500 systems
- Mitsubishi MELSEC controllers
- Omron CompactLogix and Sysmac platforms
- Any application requiring 24V DC signal indication with screw terminal connection
Replaces / Drop-In Replacement For
- Earlier Werma 829 series single-mode beacon units
- Generic 98 mm red LED beacon lights rated for 24V DC
- Verify compatibility with your system integrator before ordering for critical applications
Works With
- Standard DIN rail mounted 24V power supplies
- Programmable Logic Controllers (PLC) digital output modules
- Industrial Ethernet networks (as indicator light only, not networked sensor)
- Cabinet-mounted signal tower and beacon stacks
- External relay and contactor logic circuits
- Safety-rated control systems (verify SIL rating requirements with manufacturer)
