Overview
Weidmüller 101030 is a modular PE (protective earth) terminal block engineered for secure grounding connections in industrial control cabinets and electrical assemblies. The 1010300000 is a Modular PE Terminal Block with screw connection and 10mm² wire cross section area, featuring M4 clamping screw and 12mm stripping length. The WPE 10 terminal block accepts 16AWG minimum to 6AWG maximum wire size. This DIN rail–mounted solution combines robust construction with field-proven reliability for electrical signal distribution.
Key Features
- Screw connection technology – M4 clamping mechanism for reliable, repeatable conductor termination
- Modular design – Stackable, space-efficient DIN rail mounting
- Broad wire range – Accepts AWG 16 to AWG 6 (10mm² conductor cross-section)
- Green/yellow color coding – Meets grounding safety standards for immediate visual identification
- W-series construction – Hardened steel with tin-coated copper ensures corrosion resistance and durability
- TS 35 rail compatibility – Installs on standard 35mm DIN rail
Technical Specifications
- Wire cross-section: 10mm²
- Wire gauge range: AWG 16 to AWG 6
- Clamping screw: M4
- Stripping length: 12mm
- Voltage rating: 1000V
- Color: Green/Yellow
- Mounting: DIN rail TS 35 (35mm)
- Connection type: Screw terminal
- Positions: 2
- Material: Hardened steel with tin-coated copper
Typical Applications
Terminal block is used in electrical cabinets and electrical appliances for example between inputs and outputs and also between cabinet’s own internal wiring. Common uses include:
- Industrial control cabinet grounding and earthing
- PLC and automation panel assemblies
- Machine tool electrical distribution
- Power distribution interconnect points
- Signal conditioning and relay terminal consolidation
Compatibility & Replacements
Compatible With
- Standard 35mm (TS 35) DIN rail systems
- Weidmüller W-series terminal block systems
- Industrial control cabinet assemblies
- Allen-Bradley, Siemens, Mitsubishi, and other major PLC platforms using standard DIN rail mounting
Replaces / Drop-In Replacement For
The 101030 is the direct successor and replacement for earlier Weidmüller PE terminal block designs. Verify compatibility with your original equipment documentation before substituting older models.
Works With
- Standard metric wire terminals and ferrules (10mm²)
- DIN 43650 connector systems
- IEC 60947–1 compliant terminal strip assemblies
- Phoenix Contact and other third-party modular terminal block ecosystems using TS 35 rail
