Overview
The VOSS FRG S16 hydraulic tee fitting is a precision-engineered union T connector designed for hydraulic systems requiring three-point fluid distribution. Built with galvanized steel and featuring a cutting ring (olive) connection method, this fitting conforms to ISO/DIN standards and delivers reliable, repeatable connections in industrial and mobile hydraulic applications.
Key Features
- Cutting ring (olive) connection method for leak-free, vibration-resistant seals
- Galvanized steel body resists corrosion in demanding environments
- DIN-compliant design compatible with standard hydraulic system architectures
- Equal-bore tee configuration for balanced flow distribution
- Compact, field-proven construction for installation in tight spaces
Technical Specifications
- S16 nominal tube size (16 mm OD)
- Connection method: Cutting ring (olived compression fitting)
- Material: Galvanized steel
- Configuration: Equal tee (all three ports same size)
- DIN standard: ISO 1254 / DIN 2353
- Pressure rating: PN 420 bar (typical for S16 series)
- Operating fluid: Mineral oil hydraulic fluid (HLP per ISO 11158)
Typical Applications
- Industrial hydraulic presses and manufacturing equipment
- Mobile equipment and plant construction fluid lines
- Three-way branch connections in pressure and return lines
- Pump distribution manifolds requiring compact T-junctions
- Maintenance and field replacement in existing DIN systems
Compatibility & Replacements
Compatible With
- DIN 2353 / ISO 1254 hydraulic tubing (16 mm OD metric tube)
- Standard 16 mm cutting ring nut and ferrule assemblies
- ISO HLP mineral oil-based hydraulic fluids
- Hydraulic systems rated PN 420 bar and below
- Industrial plant and mobile equipment manifold blocks
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. VOSS FRG S16 tee fittings are designed as direct replacements for existing VOSS and equivalent DIN-standard S16 tee connections in cutting ring networks.
Works With
- VOSS cutting ring tubing systems and compression fittings
- ES-4 and standard cutting ring seal technologies
- DIN / ISO industrial hydraulic component networks
- Manifold and sub-plate hydraulic assemblies
- Field-serviceability with standard hydraulic hand tools
