Overview
The Venture Lighting V90D2311K is a 1000W high-pressure sodium (HPS) ballast engineered for reliable performance in commercial and industrial lighting systems. This ballast is specifically designed for use with ANSI S52 standard HPS lamps and features a quad-tap voltage input of 120/208/240/277V, allowing flexible installation across a range of electrical systems.
Key Features
- 1000W HPS rated ballast for ANSI S52 lamps
- Four-tap voltage input: 120V, 208V, 240V, or 277V
- Constant Wattage (CW) circuit type for stable lamp operation
- Pre-wired kit with oil-filled capacitor and integral ignitor
- Includes mounting bracket and adapter hardware
- UL and CSA certified for North American applications
Technical Specifications
- Lamp Type: ANSI S52 HPS, 1000W
- Voltage Options: 120V / 208V / 240V / 277V (quad-tap)
- Circuit Type: CWA (Constant Wattage with Autotransformer)
- Power Factor: 90%
- Maximum Operating Temperature: 100°C
- Ballast Type: Core and Coil
- Capacitor: Oil-filled
- Certifications: UL, CSA
Typical Applications
The V90D2311K is ideal for:
- Outdoor area and parking lot lighting
- Street and roadway illumination
- High-bay and warehouse lighting
- Industrial plant lighting
- Security and perimeter lighting
Compatibility & Replacements
Compatible With
- ANSI S52 HPS lamps (1000W)
- Standard HPS fixtures rated for 1000W service
- Electrical systems with 120V, 208V, 240V, or 277V service
- Three-phase or single-phase installations (via appropriate voltage selection)
Replaces / Drop-In Replacement For
Verify specific model compatibility with your fixture manufacturer before ordering. The V90D2311K is designed as a direct replacement for other Venture 1000W S52 ballasts using the same mounting pattern and electrical configuration.
Works With
- Standard HPS lamp fixtures with S52 sockets
- Wet and dry location fixtures (standard HPS ballast-compatible housings)
- Existing ignitor and capacitor systems (included in kit)
