Overview
The Veeder-Root VC773-542 VersaCount XP is a compact multifunction electronic counter designed for industrial automation and process control. This 1/16 DIN size (48mm square) unit features a 6-digit backlit green LCD display and delivers versatile functionality for counting, timing, rate measuring, position indicating, volume measurement, and speed monitoring applications. With USB programmability and dual relay outputs, the VC773-542 offers flexibility and reliability for demanding industrial environments.
Key Features
- 6-digit backlit green LCD display with 2-line capability
- Fast input frequency up to 60 kHz for high-speed counting applications
- Dual relay outputs and solid-state output options
- Three programmable presets with relay hold times up to 10 minutes
- USB programmable with proprietary Programming Assistant software
- Adjustable prescaler from 0.0001 to 99.9999 for precision control
- Compact 1/16 DIN panel mount form factor
Technical Specifications
- Display: 6-digit, backlit green LCD, 9.3mm digit height
- Input Frequency: Up to 60 kHz
- Power Supply: 100–240 VAC
- Outputs: 2 relay outputs, 3 solid-state outputs (configurable)
- Presets: Up to 3 programmable presets
- Programming Interface: USB, proprietary software
- Panel Cutout: 45mm height × 45mm width
- Operating Temperature: 0°C and above
- Dimensions: 48mm × 48mm (1/16 DIN size)
- Certifications: UL recognized, CE compliant
Typical Applications
The Veeder-Root VC773-542 is ideal for:
- Batch counting and piece counting operations
- Production line speed monitoring and rate measurement
- Position indication and length cutting control
- Volume and flow measurement
- Timing and elapsed time applications
- High-frequency encoder-based counting (up to 60 kHz)
- OEM equipment integration requiring compact panel mounting
Compatibility & Replacements
Compatible With
- Industrial control systems requiring DIN panel-mount counters
- USB-based programming and configuration platforms
- Veeder-Root Programming Assistant software
- Standard industrial relay networks and automation systems
- AC power supplies rated 100–240 VAC, 50/60 Hz
Replaces / Drop-In Replacement For
The VC773-542 is a member of the VersaCount XP series. Similar compatible models in the series include VC773-342 (white display) and VC773-442 (red display), which share the same 1/16 DIN form factor and feature set. Verify compatibility with your system integrator before ordering.
Works With
- Veeder-Root Programming Assistant software suite
- USB connectivity for program upload and download
- Ethernet connectivity (on VersaCount XP VC773 and VC774 series)
- Standard industrial relay logic and control circuits
- High-frequency encoder inputs (up to 60 kHz pulse rates)
