Overview
The Universal Dynamics PCB-090C Echo Systems Station Control Main Board is a microprocessor-based controller designed for industrial automation, building management, and distributed control applications. This board functions as a networked station controller, enabling real-time process monitoring and system coordination across HVAC systems, paper processing equipment, and other industrial environments requiring reliable networked control.
Key Features
- Integrated Echelon LPT-11 transceiver module for LON (Local Operating Network) communication
- 40-42VDC input power with regulated 5V internal logic supply
- 5MHz crystal oscillator for stable timing and synchronization
- Address selector switches for flexible network configuration
- Microprocessor-based control architecture for reliable automation performance
- Supports differential Manchester encoding on power-line transmission
Technical Specifications
- Input Voltage: 40–42VDC
- Internal Supply: Regulated 5V for logic circuits
- Communication Protocol: LON (Local Operating Network) via Echelon LPT-11
- Encoding: Differential Manchester
- Clock Speed: 5MHz crystal oscillator
- Configuration: Address selector switches for network ID assignment
- Manufacturer: Universal Dynamics
- Part Number: PCB-090C
Typical Applications
- HVAC control systems and building automation networks
- Paper processing and manufacturing equipment coordination
- Distributed industrial process controllers requiring LON communication
- Multi-station networked control environments
- Building automation system integration and expansion
Compatibility & Replacements
Compatible With
- Echelon LON (Local Operating Network) networks and devices
- Universal Dynamics Echo Systems control architecture
- Power-line carrier communication systems using differential Manchester encoding
- Building automation and HVAC control networks
- Distributed industrial control environments
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or controls engineer before ordering. The Universal Dynamics PCB-090C is a specific station control board; replacement decisions should be validated against your system architecture and communication protocol requirements.
Works With
- Echelon LON (Local Operating Network) communication protocol
- Echelon LPT-11 transceiver modules
- Building management system (BMS) software supporting LON networks
- HVAC control software and industrial automation platforms compatible with networked controllers
- Power-line carrier communication systems
