Overview
The Lantronix UDS-10-01 is an external serial-to-Ethernet device server that provides a cost-effective solution for connecting serial devices to modern networks. The UDS10 is a single-port device server that provides a quick, simple, and cost-effective way to bring the advantages of data accessibility and remote management to devices not currently connected to a network. The UDS-10-01 comes with a 110VAC power supply and is well-suited for industrial automation, control systems, and legacy equipment networking applications.
Key Features
- Half duplex 10Base-T Ethernet connectivity via RJ45 connector
- Female DB-25 connector (DCE pinout) serial interface with selectable RS-232C or RS-422/485
- Software-selectable baud rates from 300 to 115kBaud
- Web Manager and Telnet-based configuration interface
- 128kByte RAM with 512kByte Flash PROM storage
- Multiple connection modes including Standard Tunnel Protocol and modem mode emulation
Technical Specifications
- Processor: AMD 188ES CPU, 25MHz clock
- Memory: 128kByte RAM, 512kByte Flash PROM
- Network Interface: 10 Mbps RJ45 Ethernet
- Serial Interface: Female DB-25 (DCE pinout), selectable RS-232C or RS-422/485
- Baud Rate: software selectable 300 to 115kBaud
- Power Supply: ships with 12VDC 1A supply; 110VAC version (UDS-10-01) available
- Input voltage: 9-30VDC
- Configuration: Web browser, Telnet, serial port, or DeviceInstaller utility
- IP Assignment: DHCP, BOOTP, AutoIP, or static IP
Typical Applications
The Lantronix UDS-10-01 is commonly deployed in:
- Industrial automation systems requiring serial equipment remote access
- Factory control systems needing Ethernet integration without protocol changes
- Legacy device networking and device management
- Point-of-sale (POS) terminal network integration
- Energy management and SCADA applications
- COM port redirection over Ethernet networks
Compatibility & Replacements
Compatible With
- Any serial device with RS-232, RS-422, or RS-485 interface
- Ethernet networks with DHCP or static IP capability
- Telnet-enabled network management systems
- DeviceInstaller software utility (Windows-based configuration)
- Lantronix DeviceComm Manager serial port redirector software
- Standard TCP/UDP network protocols
Replaces / Drop-In Replacement For
- The UDS1100 device server is a direct replacement offering improved features and complete drop-in compatibility
- UDS-10 (12VDC version)
- Serial terminal servers in similar legacy applications
Works With
- Serial tunneling protocol for transparent serial data transmission over Ethernet
- Modbus protocol support (UDS-10-IAP variant)
- DF1 protocol support (UDS-10-IAP variant)
- TCP/IP and UDP datagram-based communication
- DHCP, BOOTP, and AutoIP network configuration protocols
- Any legacy application software without modification—acts as transparent serial-to-Ethernet bridge
