Overview
The Turck PKG 3M-7.6-PSG 3M/S90/S101 is a 7.6-meter double-ended sensor cordset designed for industrial automation and control applications. This cordset features M8 connectors with straight male and female ends, making it ideal for extending distances between sensors, actuators, and control modules. The yellow PVC jacket and rugged construction ensure reliable performance in harsh factory and machine environments.
Key Features
- 7.6-meter cable length for extended sensor placement flexibility
- M8 3-pin connector configuration (S90/S101 straight male and female)
- Double-ended design — female connector on one end, male on the other
- Yellow PVC jacket with -40°C cold bend rating
- 3×24 AWG stranded copper conductors for reliable signal transmission
- CSA FT1 rated — suitable for general industrial automation
Technical Specifications
- Cable Length: 7.6 meters
- Connector Type: M8 3-pin, threaded
- Connector Configuration: Straight female to straight male (S90/S101)
- Conductor Size: 3×24 AWG
- Jacket Material: Yellow PVC
- Temperature Rating: -40°C cold bend to +70°C operating
- Standards: CSA FT1 (Fire-resistant cable)
- Shielding: General purpose (unshielded)
- Compatible Models: Turck sensor and actuator systems using M8 Picofast connectors
Typical Applications
- Industrial sensor extension cabling (proximity, pressure, temperature sensors)
- Actuator and solenoid valve connections
- Machine automation control systems
- Assembly and packaging line equipment
- CNC machine tool automation
- Pneumatic and hydraulic system control
Compatibility & Replacements
Compatible With
- Turck M8 sensor and actuator products
- Turck Picofast connector ecosystem
- Industrial PLC and automation controller I/O modules with M8 connectors
- Standard M8 3-pin threaded female and male connectors
Replaces / Drop-In Replacement For
- Other Turck 7.6m double-ended M8 cordsets in the PKG 3M series
- Generic M8 3-pin cordsets with equivalent -40°C rating
- Verify exact connector end configuration (S90/S101) with your system integrator before ordering to ensure proper polarity and pinout match.
Works With
- Turck TLE (Terminal Lever Extension) sensor systems
- Turck IO-Link compatible devices via standard M8 interface
- Standard M8 sensor networks and industrial Ethernet gateways
- Any PLC or automation controller supporting M8-based analog or digital sensor input
