Overview
The Trumeter 3602-111TG mechanical totalizing counter delivers robust, maintenance-free operation in demanding industrial environments. Part of Trumeter’s proven 3602 Series, this unit is specifically configured for top-going drive direction with feet and inches measurement capability and 1:1 gear ratio. It records rotating or reciprocating movement on power winding, measuring, and production machinery throughout continuous manufacturing cycles.
Key Features
- 6-digit mechanical readout — front-facing display for easy viewing at operational speeds
- Top-going drive direction — shaft rotates away from operator for proper tracking when material moves toward the operator
- Bidirectional counting — adds in one direction, subtracts in reverse for accurate net measurement
- Quick reset mechanism — rapid zeroing without stopping production
- High-speed capability — operates reliably at up to 3000 counts per minute with 1:1 gearing
- Dual oil-impregnated bearings — ensures long-term trouble-free operation and minimal maintenance
Technical Specifications
- Display: 6-digit mechanical counter with one decimal place
- Measurement Units: Feet and Inches
- Gear Ratio: 1:1
- Drive Direction: Top Going
- Maximum Count Speed: 3000 counts per minute (1:1 ratio)
- Construction: ABS plastic with double oil-impregnated main shaft bearings
- Counting Direction: Bidirectional (forward and reverse)
- Reset Type: Mechanical quick reset
Typical Applications
- Power winding and yarn measurement systems
- Fabric and film production length tracking
- Conveyor and material handling equipment monitoring
- Cable and wire dispensing machines
- Continuous manufacturing lines requiring precise length recording
- Textile, packaging, and print production facilities
Compatibility & Replacements
Compatible With
- Any dual-shaft mechanical drive system with top-going rotation requirement
- Power winding and measuring machine assemblies
- Production equipment requiring feet/inches length measurement
- Direct-drive and geared shaft applications at 3000 CPM maximum
Replaces / Drop-In Replacement For
- Earlier Trumeter 3602-111TG units
- Other mechanical counters with equivalent feet/inches 1:1 configuration
- Units used in 2300/2400/2700 Series assembly applications
Works With
- No electronic controls or software required — purely mechanical operation
- Mechanical shaft couplings and direct drive arrangements
- Pulley and belt-drive systems (verify torque limitations with Trumeter)
- Production line control systems that read mechanical counter displays
