Overview
The Triad F-270X is a chassis-mount power transformer engineered for industrial electronics, audio/video equipment, and control circuits. This transformer steps down 115VAC primary voltage to 40VCT (center-tap) secondary output at 1.0A, supporting both 50Hz and 60Hz operation for global deployment. The center-tap secondary configuration enables flexible rectification options for power supply designs.
Key Features
- Center-tap secondary (40VCT) for full-wave rectifier circuits
- Dual-frequency operation: 50Hz and 60Hz
- Chassis-mount construction with lead connections
- 1.0A secondary current rating
- Standard industrial-grade transformer reliability
Technical Specifications
- Primary Input Voltage: 115VAC
- Secondary Output Voltage: 40VCT (center-tap)
- Secondary Current Rating: 1.0A
- Frequency: 50/60Hz dual-frequency
- Mounting Style: Chassis mount with leads
- VA Rating: 40VA (calculated at 40V × 1.0A)
- Isolation: Transformer isolated primary-to-secondary
Typical Applications
- Audio amplifier power supplies and pre-amplifier stages
- Vintage and tube equipment restoration and repair
- Industrial control circuit power conditioning
- Video and broadcast equipment power distribution
- Laboratory test benches and measurement instruments
Compatibility & Replacements
Compatible With
- Full-wave center-tap rectifier circuits (silicon or selenium diodes)
- Bridge rectifier configurations (secondary secondary winding)
- Tube and solid-state audio amplifier designs
- Industrial control and instrumentation systems operating at 115VAC
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. Similar Triad transformer models in the F-series may have different voltage or current ratings; confirm exact part number and specifications prior to substitution.
Works With
- Full-wave rectifier topologies using center-tap secondary
- Silicon and selenium rectifier diodes
- AC line filtering and power conditioning circuits
- Standard 115VAC / 50–60Hz mains power systems
