Overview
The TPC 55445 Kord-Gard Super-Trex is a straight cord grip fitting designed for industrial cable management and strain relief. This 1″ NPT model accommodates cable outer diameters from .745″ to 1.00″ and provides reliable cable entry protection in electrical enclosures, machinery, and equipment installations.
Key Features
- 1″ NPT straight fitting design for direct cable entry
- Accommodates .745″–1.00″ cable O.D. range
- Proven Kord-Gard strain relief technology
- Compatible with Super-Trex portable cord systems
- Industrial-grade construction for harsh environments
- New, in-box condition
Technical Specifications
- Manufacturer: TPC Wire & Cable
- Model Number: 55445
- Fitting Type: Straight Kord-Gard
- NPT Size: 1″ NPT
- Body Bore (A): 1.06 inches
- Dimension B: 0.69 inches
- Dimension C: 1.91 inches
- Body Hex (D): 2.00 inches
- Nut Diameter (E): 2.47 inches
- Cable O.D. Range: .745″ – 1.00″
- Condition: New in Box
Typical Applications
- Cable entry protection in electrical control enclosures
- Strain relief for flexible portable cords on machinery
- Industrial equipment and panel installations
- Applications requiring 1″ NPT threaded entry points
- Environments with impact, abrasion, or cable movement concerns
Compatibility & Replacements
Compatible With
- Super-Trex Triple-Gard portable cord systems (Black, Yellow variants)
- Super-Trex Ultra-Gard portable cords
- TPC Wire & Cable portable cord products
- Standard 1″ NPT threaded enclosures and junction boxes
- Industrial electrical cabinets and control panels
Replaces / Drop-In Replacement For
- Other 1″ NPT straight Kord-Gard fittings in the 55xxx series
- Compatible with equivalent straight cord grip models for 1″ NPT applications
Works With
- TPC Super-Trex portable cord product line
- Standard 1″ NPT electrical enclosure ports
- Flexible industrial power cords and cable assemblies
- Cable management and strain relief systems
