Overview
The TE Connectivity PT9101-0250-221-1130 string potentiometer is a position transducer engineered for accurate resistance and voltage divider applications. Part of TE Connectivity’s Measurement Specialties line, this sensor provides linear measurement capability essential for control systems, positioning equipment, and diagnostic instrumentation across industrial automation, manufacturing, and material handling sectors.
Key Features
- Voltage divider position transducer design for direct analog feedback
- High-reliability construction suitable for industrial environments
- Precision linear measurement output
- TE Connectivity brand engineering and quality assurance
- Compact form factor for space-constrained installations
Technical Specifications
Verify all specifications with TE Connectivity documentation before final integration:
- Manufacturer: TE Connectivity Measurement Specialties
- Part Number: PT9101-0250-221-1130
- Product Type: String Potentiometer / Voltage Divider Position Sensor
- Operating Range: 250 mm (derived from part number designation)
- Output Type: Analog Voltage Divider
- Connector Type: 4-pin connector (standard for PT9101 series)
Typical Applications
- Linear position measurement in manufacturing equipment
- Hydraulic and pneumatic cylinder position feedback
- Control and regulation systems requiring analog input
- Material handling and robotic applications
- Test stands and measurement instrumentation
- Diagnostic and monitoring systems
Compatibility & Replacements
Compatible With
- Industrial control systems accepting 4-20 mA or 0-10 V analog input
- PLC analog input modules
- Data acquisition systems and measurement devices
- Legacy and modern positioning control systems
- TE Connectivity PT9101 series mounting infrastructure
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The PT9101-0250-221-1130 may be compatible with other PT9101 variants depending on connector pinout and voltage specifications. Consult TE Connectivity documentation or contact technical support for cross-reference information.
Works With
- Analog input terminals (4-20 mA / 0-10 V standard ranges)
- SCADA and HMI systems with analog data acquisition
- Industrial Ethernet networks with analog I/O gateways
- Legacy hardwired control panels and analog instrumentation
