Overview
The T2007-11SM is a miniature tongue-operated safety interlock switch with 1NC + 1NO contact, 1 x M16 with NPT adapter wiring entry and 1NC positive break safety contact. Ideal for smaller machines with space restrictions. The Omron STI T2007-11SM delivers safety-critical switching in the industry’s smallest tongue-operated form factor, making it a top choice for system integrators working with compact machine enclosures and restricted mounting spaces.
Key Features
- Small swing radius allows use on doors with a swing radius as small as 2.5-inch when using the flex actuator with stainless steel guide.
- Rotatable head gives 8 possible actuator entry points for versatile installation.
- NEMA 6 enclosure enables the T2007 with conduit entry or connector to withstand water wash down cleaning.
- Designed for one million actuations with its stainless steel actuators and optional stainless steel guide.
- Fits on 1-inch square tubing.
Technical Specifications
The T2007-11SM features force-guided contacts with a tamper-resistant mechanism for safety compliance. Contact voltage AC max is 500V, contact current AC max is 5A, contact voltage DC max is 250V, and contact current DC max is 2A. Operating temperature range is -4°F to 176°F (-20°C to 80°C), with IP67 / NEMA 6 rating and glass-filled polyester body material. M16 conduit entry with 1/2″ NPT adapter is standard.
Typical Applications
- Small machine tool safety gates and access covers
- Compact press and punch machine interlocks
- Laboratory equipment and test stand enclosures
- Injection molding machine guards with space constraints
- Washdown environments requiring corrosion resistance (NEMA 6)
- OEM equipment where 1-inch tubing mounting is preferred
Compatibility & Replacements
Compatible With
- Dual-channel safety controllers and safety PLCs
- Safety relay modules with dual-channel input capability
- Emergency stop circuits and safety logic systems
- Standard industrial control enclosures with M16 conduit entry
- 1-inch square tubing framing and machine frames
Replaces / Drop-In Replacement For
The T2007-11SM with 90° actuator is the rotatable-head variant of the T2007 series. Other T2007 variants include the T2007-11TM (flat actuator), T2007-11TC (flat actuator with connector), T2007-11F1 (flex actuator with stainless steel guide), and T2007-11SC (90° actuator with connector). When replacing existing T2007 models, verify actuator style (flat, flex, or 90°) and wiring entry type (conduit or connector) for compatibility.
Works With
- Siemens S7-1200, S7-1500 safety controllers
- Allen-Bradley CompactLogix and ControlLogix safety modules
- Omron NX-series safety controllers
- Pilz safety relay and control systems
- Standard dual-channel safety circuits per ISO 13849-1 PLd/e and SIL 2
