<h2>Overview</h2>
<p>The <strong>Stabilus Lift-O-Mat 192953-0250N</strong> is a non-locking gas spring engineered for reliable lifting and lowering of panels, covers, lids, and doors in industrial and commercial applications. This hydropneumatic actuator combines precision engineering with durable steel construction to deliver consistent counterbalancing and smooth motion control.</p>
<h2>Key Features</h2>
<ul>
<li>250 Newton (N) lifting force—ideal for light to medium-duty support applications</li>
<li>Steel construction with eyelet mounting brackets on both piston rod and pressure tube</li>
<li>Compact 106 mm extended length; 20 mm controlled stroke for precise positioning</li>
<li>Nitrogen gas-filled pressure tube with adjustment capability for fine-tuning performance</li>
<li>Excellent damping characteristics minimize shock and sudden movement</li>
<li>Proven Stabilus Lift-O-Mat reliability—widely used in industrial equipment and cabinet applications</li>
</ul>
<h2>Technical Specifications</h2>
<ul>
<li><strong>Model:</strong> 192953-0250N</li>
<li><strong>Lifting Force:</strong> 250 N (Newton)</li>
<li><strong>Total Extended Length:</strong> 106 mm</li>
<li><strong>Stroke:</strong> 20 mm</li>
<li><strong>Pressure Tube Length:</strong> 52 mm</li>
<li><strong>Piston Rod Diameter:</strong> 6 mm</li>
<li><strong>Pressure Tube Diameter:</strong> 15 mm</li>
<li><strong>Material:</strong> Steel</li>
<li><strong>End Shape:</strong> Eyelet (both ends)</li>
<li><strong>Weight:</strong> 0.04 kg</li>
<li><strong>Internal Medium:</strong> Nitrogen gas (adjustable)</li>
<li><strong>Manufacturer:</strong> Stabilus GmbH (Koblenz, Germany)</li>
</ul>
<h2>Typical Applications</h2>
<ul>
<li>Panel, cover, and door lift-assist in machinery enclosures</li>
<li>Cabinet and equipment lid support</li>
<li>Industrial access hatches and service panels</li>
<li>Controlled lowering in test benches and work stations</li>
<li>General counterbalancing where 250N force is required</li>
</ul>
<h2>Compatibility & Replacements</h2>
<h3>Compatible With</h3>
<ul>
<li>Any mounting system accepting 6 mm rod diameter and 15 mm tube diameter eyelet brackets</li>
<li>Standard industrial panel and door hinge systems requiring 250N support force</li>
<li>Equipment designed for Stabilus Lift-O-Mat family gas springs</li>
</ul>
<h3>Replaces / Drop-In Replacement For</h3>
<ul>
<li>Original equipment Stabilus Lift-O-Mat 192953 units in 250N rating</li>
<li>Equivalent 250N, 106 mm length gas springs from other manufacturers with matching eyelet dimensions</li>
</ul>
<h3>Works With</h3>
<ul>
<li>Eyelet pin hinges and pivot mounts (6 mm rod compatible)</li>
<li>Standard industrial fastening hardware</li>
<li>Any equipment OEM specification calling for Stabilus 192953-0250N or equivalent 250N Lift-O-Mat</li>
</ul>
