Overview
The Square D 9007G /A is a direct-action limit switch head designed for integration into Square D’s 9007 series modular system. As part of the Class 9007 family, this unit delivers reliable position sensing and control across diverse industrial applications including packaging machinery, material handling, and automated assembly lines. The 9007G /A head design provides a cost-effective means of upgrading or retrofitting existing control systems without requiring complete switch replacement.
Key Features
- Durable die-cast construction with rugged 9.5mm diameter shaft for reliable mechanical operation
- Direct-action contact mechanism engineered for repeatable switching at rated travel
- Wide operating temperature range from −17.8°C to +85°C for harsh industrial environments
- Easy wiring access with terminal screws and captive pressure clips for field installation
- Oil-tight, dust-tight enclosure rated NEMA Types 2, 4, 6, and 13 for washdown and chemical resistance
- Modular head design compatible with standard 9007 series bodies and components
Technical Specifications
- Series: Square D Class 9007
- Head Type: 9007G /A
- Condition: New in Box
- Shaft Diameter: 9.5 mm
- Operating Temperature Range: −17.8°C to +85°C
- Overtravel Protection: Up to 85° safety over-travel
- Enclosure Rating: NEMA Types 2, 4, 6, 6P, 12, 13
- Contact Type: Direct-action silver contacts
Typical Applications
The Square D 9007G /A limit switch head is used in:
- Industrial machinery position verification and end-of-travel safety stops
- Automated material handling and conveyor systems
- Manufacturing equipment gate and guard interlocks
- Packaging and labeling machine control circuits
- Process automation requiring repeatable position sensing
- Wash-down areas, foundries, and corrosive environments where NEMA 4/13 rating is required
Compatibility & Replacements
Compatible With
- Square D 9007 series base plates and bodies
- All 9007C, 9007T, and 9007 standard box limit switch assemblies
- Direct-action control circuits rated up to 600 V AC / 10 A
- Modular limit switch systems using standard 9.5mm shaft interfaces
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or contact technical support before ordering, as head compatibility depends on the specific 9007 series base plate assembly in use. This unit is a genuine Square D / Telemecanique OEM component and is not a universal replacement for all 9007-series heads.
Works With
- Square D Class 9007 modular system components
- Telemecanique sensor ecosystem (Square D successor brand)
- Standard industrial control circuits operating at 600 V AC maximum
- Mechanical automation and machine control systems
