Overview
The Sparkle Power SPI700W7BB is a high-capacity 700W switching power supply engineered for rack-mount server applications. Featuring ATX12V and EPS12V compliance, this 2U form-factor unit delivers the distributed power architecture required by modern multi-socket server motherboards. With 80 PLUS Bronze efficiency certification and active Power Factor Correction (PFC), this supply minimizes energy waste while meeting strict power quality standards.
Key Features
- 700W nominal output capacity
- Dual voltage input (AC 115–230V), single-cable operation worldwide
- 80 PLUS Bronze efficiency certification
- Active Power Factor Correction (PFC)
- ATX12V 2.x and EPS12V compliant
- Multiple 12V rail outputs with dedicated 8-pin CPU connectors
- Additional 6+2 pin PCI Express connectors for multi-GPU configurations
- 2U form factor, optimized for rack-mount chassis
- MTBF: 100,000 hours at maximum load (+25°C)
Technical Specifications
- Power Rating: 700W
- Input Voltage: AC 115–230V, single-phase
- Efficiency: 80 PLUS Bronze certified
- Form Factor: 2U rack-mount
- Standards Compliance: ATX12V 2.x, EPS12V
- PFC Type: Active (CCC/EMI certified)
- Cooling: Thermostat-controlled fan
- MTBF: 100,000 hours at maximum load, +25°C
- Operating Temperature: 0°C to 40°C
- RoHS Compliant: Yes
Typical Applications
The SPI700W7BB is purpose-built for server and data center environments:
- Single or dual-socket server motherboards in 2U chassis
- High-performance workstation configurations
- Network infrastructure appliances (switches, routers, firewalls)
- Storage arrays and RAID controller systems
- Legacy server refresh and replacement projects
- Industrial computing and embedded systems with redundancy requirements
Compatibility & Replacements
Compatible With
- Intel and AMD dual-socket server motherboards (Xeon, EPYC)
- Standard 2U and 3U rack-mount chassis with EPS12V/ATX12V connectors
- Motherboards requiring dual 8-pin 12V CPU power connectors
- Server platforms from HP ProLiant, Dell PowerEdge, Supermicro, and IBM System x
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. Original part number SPI700W7BB; direct replacement for units with matching 2U ATX12V/EPS12V specifications and identical mounting footprint.
Works With
- ATX12V 2.x / EPS12V power distribution standards
- IPMI and out-of-band management systems (via shared thermal sensors)
- Enterprise server cooling and power distribution units (PDUs)
- Industry-standard rack power monitoring and management tools
