Overview
The Souriau MS3116F16-26P is a male circular connector designed to MIL-DTL-26482 Series I specifications. This plug connector features 26 contacts arranged in a circular configuration and is engineered for secure, high-reliability connections in demanding industrial, aerospace, and defense applications. The connector’s robust construction and military-grade specifications ensure long service life and dependable performance.
Key Features
- 26 gold-plated copper alloy contacts for corrosion resistance and reliable signal transmission
- Male plug gender with straight body orientation for standard panel mounting
- 7.5 amperes per contact maximum current rating
- Solder termination for permanent, high-strength wire connections
- MIL-DTL-26482 Series I military specification compliance
- Operating temperature range -55 to +125 °C for extreme environment reliability
Technical Specifications
- Part Number: MS3116F16-26P
- Connector Type: Circular, male plug
- Contact Count: 26 positions
- Contact Material: Copper alloy with gold plating
- Shell Size: 16-26
- Current Rating: 7.5 A/contact (maximum)
- Termination Style: Solder
- Operating Temperature: -55 to +125 °C
- Length: 51 mm
- Diameter: 32.5 mm
- Body Orientation: Straight
- Specification Standard: MIL-DTL-26482
- Mounting Type: Wire/cable mount
Typical Applications
The MS3116F16-26P is widely used in:
- Aerospace and defense systems requiring MIL-spec connectors
- Industrial control and automation equipment
- High-reliability instrumentation and test equipment
- Military vehicle and platform wiring harnesses
- Harsh environment installations with temperature extremes
- Multi-signal transmission systems requiring secure connections
Compatibility & Replacements
Compatible With
- MS3116F16-26S female receptacle connector (mating pair)
- MIL-DTL-26482 Series I compliant systems and equipment
- Aerospace and military avionics platforms
- Industrial control systems requiring circular connectors
- Custom harness assemblies and distribution panels
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or engineering team before ordering. The MS3116F16-26P is a direct mate to the MS3116F16-26S receptacle and compatible with other MIL-DTL-26482 Series I equipment rated for 26-pin shell size 16 connectors.
Works With
- MIL-DTL-26482 Series I specification standards
- Circular connector mating systems (shell size 16)
- Solder-cup contact termination equipment and processes
- Military-grade wiring harness assemblies
- Aerospace and defense integration platforms
