<h2>Overview</h2>
<p>The <strong>SolaHD SLS-12-068</strong> is a single-output linear power supply engineered for reliable 12 VDC power delivery in demanding industrial environments. Part of the Silver Line Series, this unit outputs a continuous 6.8 amp capacity with multi-voltage input support (100/120/220/230/240 VAC), making it suitable for global installations and retrofit applications.</p>
<h2>Key Features</h2>
<ul>
<li>Single 12 VDC output at 6.8 amps (81.6 W nominal)</li>
<li>Extremely low-noise, quiet DC output for noise-sensitive analog and microprocessor circuits</li>
<li>Automatic resetting overload protection and fold-back current limiting</li>
<li>Built-in over-voltage protection (OVP) with automatic recovery</li>
<li>Fast transient response ideal for test and measurement applications</li>
<li>Industry-standard footprint and screw-terminal connections</li>
<li>Optional protective covers available</li>
</ul>
<h2>Technical Specifications</h2>
<ul>
<li><strong>Output Voltage:</strong> 12 VDC </li>
<li><strong>Output Current:</strong> 6.8 A continuous</li>
<li><strong>Power Output:</strong> 81.6 W nominal (up to 244 W with multiple configurations)</li>
<li><strong>Input Voltage:</strong> 100–240 VAC multi-tap</li>
<li><strong>Input Frequency:</strong> 47–63 Hz</li>
<li><strong>Voltage Regulation:</strong> 0.5% line; 0.05% load (combined)</li>
<li><strong>Mounting:</strong> Chassis/panel mount</li>
<li><strong>Weight:</strong> 1.31 lbs</li>
<li><strong>Connection Type:</strong> Screw-terminal block</li>
<li><strong>Series:</strong> SolaHD Silver Line Linear Power Supply</li>
</ul>
<h2>Typical Applications</h2>
<p>The SLS-12-068 serves mission-critical roles in:</p>
<ul>
<li>Industrial control circuits and PLC ancillary power</li>
<li>CNC machinery and motion control systems</li>
<li>Instrumentation and test equipment</li>
<li>Microprocessor and analog circuit power</li>
<li>Drive amplifier and servo power conditioning</li>
<li>Food processing and packaging equipment</li>
<li>Noise-sensitive sensing and data acquisition</li>
</ul>
<h2>Compatibility & Replacements</h2>
<h3>Compatible With</h3>
<ul>
<li>Allen-Bradley control systems requiring 12 VDC auxiliary power</li>
<li>Siemens and Omron PLC and HMI power conditioning</li>
<li>Servo drive and motion controller ancillary supplies</li>
<li>Data acquisition and instrumentation modules</li>
<li>Universal 115/230 VAC input installations (no transformer required)</li>
</ul>
<h3>Replaces / Drop-In Replacement For</h3>
<ul>
<li>SLS-12-068T (modern variant)</li>
<li>Legacy Sola Linear 12V 6.8A units with industry-standard footprint</li>
</ul>
<h3>Works With</h3>
<ul>
<li>Screw-terminal DIN-rail adapters (third-party)</li>
<li>Enclosed panel-mount cabinets with standard cutout spacing</li>
<li>Optional SolaHD plastic or metal protective covers</li>
</ul>
