Overview
The SMC CP96SDB32-410C is a double-acting pneumatic cylinder from SMC’s CP96-C series. This model combines a 32mm bore with a 410mm stroke, making it suitable for automation and industrial control applications requiring reliable linear actuation. The CP96-C series features integrated air and bumper cushioning for smooth operation and reduced noise at end-of-stroke positions.
Key Features
- Double-Acting Design: Provides powered extension and retraction for flexible control
- Dual Cushioning System: Air and bumper cushioning reduces stroke length and cycle noise
- 32mm Bore, 410mm Stroke: Delivers consistent force and travel distance for standard automation tasks
- CNOMO Grooves: Four-sided grooved body allows easy fitting of position sensors without additional modifications
- ISO 15552 Compliant: Meets international cylinder standards for interchangeability and reliability
- Piston Rod Design: Single-rod configuration for compact mounting in space-constrained environments
Technical Specifications
- Bore Size: 32mm
- Stroke Length: 410mm
- Action Type: Double Acting
- Cushioning: Air and bumper cushioning both ends
- Rod Type: Piston rod (single)
- Mounting Grooves: CNOMO square grooves on all four sides
- Compatible Sensors: CNOMO, SMC M9, A9 position sensors
- Series: CP96-C (ISO 15552)
- Pressure Range: Standard industrial pneumatic pressure (consult datasheet for exact range)
- Port Connections: SAE ports (verify exact specifications with datasheet)
Typical Applications
The SMC CP96SDB32-410C is widely used in:
- Manufacturing automation and assembly lines
- Material handling and positioning systems
- Industrial machinery and equipment
- Automated packaging and labeling systems
- Process control and pneumatic actuation systems
Compatibility & Replacements
Compatible With
- Standard pneumatic control systems using compressed air
- Industrial automation platforms with pneumatic actuation
- SMC valve blocks and directional control valves
- CNOMO and circular groove position sensor mounting systems
- M9 and A9 series proximity sensors
Replaces / Drop-In Replacement For
- Other CP96 series cylinders with identical bore/stroke specifications
- ISO 15552 compliant 32mm bore cylinders from compatible manufacturers
Works With
- SMC CNOMO position sensors
- SMC M9 and A9 series auto switches
- Standard pneumatic directional control valves
- Industrial PLC and automation control systems
