Overview
The SMC CDJ2B16-60-B is a double-acting band mount cylinder from SMC’s CJ2 series. This compact, round-body pneumatic cylinder delivers reliable linear motion for automation, robotics, and industrial control applications. With its 16 mm bore and 60 mm stroke, the CDJ2B16-60-B offers proven performance in space-constrained installations where standard foot-mounted cylinders may not fit.
Key Features
- Double-acting configuration for push and pull motion
- Band mounting style enables flexible installation on existing frame structures
- 16 mm bore diameter with 60 mm standard stroke
- Compact, round-body design reduces footprint
- Built-in magnet option available for proximity sensing and auto-switch integration
- Multiple mounting bracket and accessory options available
Technical Specifications
- Bore Size: 16 mm (ø16)
- Stroke: 60 mm
- Type: Double-Acting
- Mounting Style: Band Mount (B)
- Series: CJ2 Round Body
- Body Style: Round
- Port Configuration: Available with multiple port locations
- Operating Medium: Compressed air
- Cushion Option: None or rubber bumper available
- Auto Switch: Provisions for built-in magnet and auto-switch mounting
Typical Applications
- Assembly machinery and fixture clamping
- Material handling systems and conveyors
- Automated packaging and labeling equipment
- Robotics and pick-and-place automation
- Test and measurement equipment
- Industrial process control and positioning
Compatibility & Replacements
Compatible With
- SMC CJ2 series mounting brackets and accessories
- Standard ISO 4401 pneumatic control valves
- Air regulators and flow control valves
- Manual and solenoid directional control valves
- Proximity sensors and auto-switch systems with built-in magnet compatibility
- PLC and industrial automation control systems
Replaces / Drop-In Replacement For
- Other SMC CJ2 band-mount cylinders with equivalent bore and stroke ratings
- Legacy pneumatic cylinder models requiring 16 mm bore, 60 mm stroke specifications
- Note: This is a legacy product; verify cross-compatibility with your system integrator before ordering
