Overview
The Siemens 00322546 S 01 is a Type 419 multifunctional nozzle engineered for Siemens SIPLACE ASM SMT pick and place systems. This OEM-original nozzle is a precision suction component that enables accurate placement of electronic components during surface mount assembly. The Type 419 designation identifies this as a multifunctional nozzle optimized for versatile component handling across diverse PCB assembly applications.
Key Features
- Multifunctional design: Supports pickup and placement of multiple component sizes and types within a single machine configuration
- OEM-original component: Genuine Siemens part for guaranteed SIPLACE ASM compatibility and performance
- Precision vacuum interface: Reliable suction mechanism for consistent component grip during transport and placement
- Proven reliability: Extensive deployment across SMT assembly lines for high-volume production
- New condition: Factory-sealed OEM packaging with full warranty coverage
Technical Specifications
- Part Number: 00322546 S 01
- Type Designation: Type 419 Multifunctional
- Complete Assembly: 00322546-03
- Application: Siemens SIPLACE ASM pick and place machines
- Component Category: Suction nozzle assembly
- Condition: New in box, OEM original
- Vacuum Interface: Standard SIPLACE ASM mount
- Material: High-performance engineering plastic
Typical Applications
The Type 419 nozzle is deployed in high-speed SMT assembly environments including:
- PCB assembly and component placement on Siemens SIPLACE ASM D-series, H-series, and X-series machines
- Mixed-component pickup for passives (resistors, capacitors) and small actives (transistors, diodes)
- Production environments requiring flexible, single-nozzle configuration for multiple placement heights
- Maintenance replacement and system refresh for existing SIPLACE ASM installations
Compatibility & Replacements
The Siemens 00322546 S 01 Type 419 nozzle is a direct OEM replacement component for Siemens SIPLACE ASM systems equipped with Type 419 nozzle stations. The complete assembly number is 00322546-03. This part integrates with standard SIPLACE ASM vacuum distribution systems and is not interchangeable with other Type designations (such as Type 416, 417, 418, or higher-series types). For system upgrades or multi-nozzle configurations, consult Siemens technical documentation or contact your system integrator.
