Overview
Schneider Electric NSYTRAP22 partition plates are precision-engineered accessories for Linergy TR screw terminal block installations. Each bag contains 50 gray plastic plates designed to maintain proper spacing and organization in electrical control panels and switchgear. These plates are ideal for separating terminal block positions and improving wiring clarity in high-density terminal applications.
Key Features
- 50 plates per bag—bulk pack reduces component ordering
- 2 mm height for standard Linergy terminal block spacing
- Gray plastic construction rated for industrial environments
- Screw-mount compatibility with TRV series terminals
- RoHS and REACH compliant—meets green standards
- Certified to ATEX, CSA, DNV, EAC, GL, IECEx, LR, UL, and VDE standards
Technical Specifications
| Part Number | NSYTRAP22 |
| Manufacturer | Schneider Electric (Square D) |
| Product Type | Partition/Separator Plate |
| Color | Gray |
| Material | Plastic |
| Height (Depth) | 2 mm (0.0787 in) |
| Length | 1.97 in (50.04 mm) |
| Width | 2.17 in (55.1 mm) |
| Quantity Per Bag | 50 plates |
| Wire Range | 2.5–10 mm² |
| Mounting Type | Screw mount |
| Certifications | ATEX, CSA, DNV, EAC, GL, IECEx, LR, UL, VDE |
| RoHS / REACH | Compliant |
| Country of Origin | Poland |
Typical Applications
- PLC and control panel wiring organization
- Industrial switchgear assembly and maintenance
- High-density terminal block configurations
- Blade disconnect terminal block separation
- Passthrough terminal block partitioning
- Protective earth terminal block organization
Compatibility & Replacements
Compatible With
- Linergy TR screw terminal blocks
- Schneider NSY series terminal blocks
- NSYTRV22, NSYTRV22BL, NSYTRV42, NSYTRV42BL, NSYTRV62 terminal models
- TRV screw terminal assemblies (single-level 1×1)
- Standard industrial control enclosures
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. Consult Schneider Electric technical documentation or contact our sales team for specific replacement cross-references.
Works With
- Linergy TR terminal block systems
- NSY series enclosure accessories
- ATEX/IECEx certified control panel installations
- UL/CSA listed switchgear configurations
- PROFINET and standard industrial networks (terminal accessory—protocol agnostic)
