Overview
The Schneider Electric NSYTRV22PE is a protective earth terminal block from Schneider’s trusted Linergy TR series. This 2-position 1-level green/yellow protective earth terminal block features screw connection, designed for safe and reliable grounding in electrical distribution and control systems. It belongs to the Linergy earth terminal block family with 2.5 mm² nominal cross section and green-yellow surface treatment.
Key Features
- Clip-on mounting with single-level 1×1 screw terminals
- Connection and disconnection by screwdriver
- Accommodates 26 to 12 AWG wire with 0.35 in wire strip length and 0.5 to 0.6 N-m torque specification
- Certified to standards UL, CSA, VDE, ATEX, IECEx, GL, LR, DNV with polyamide 6/6 material
- RoHS/REACH compliant with Green Premium certification
- Compatible with Schneider enclosures including Prisma G, Prisma P, Pragma, Prisma PH, Prisma Pack, Spacial, Kaedra, and TeSys
Technical Specifications
Wire gauge compatibility, temperature tolerance, and mounting details ensure this terminal block meets industrial control requirements across manufacturing, distribution, and infrastructure applications.
Typical Applications
- Industrial control panel and switchboard assembly
- DIN rail-mounted protective earth distribution
- Manufacturing and process automation systems
- Commercial and light industrial electrical installations
- Equipment grounding in harsh and ATEX-classified environments
Compatibility & Replacements
Compatible With
- Schneider Electric Linergy TR terminal block systems
- DIN rail-mounted control cabinets and distribution boards
- Industrial control platforms requiring IEC protective earth connections
- Standard 35 mm DIN rail installations
Replaces / Drop-In Replacement For
The NSYTRV22PE is the standard 2-position green-yellow protective earth terminal from Schneider’s Linergy TR range. Verify compatibility with your existing installation before ordering.
Works With
- Schneider Electric Prisma G, P, PH, and Pack enclosures
- TeSys industrial control systems
- Spacial and Kaedra distribution cabinets
- IEC-compliant 35 mm DIN rail mounting systems
- Standard electrical safety protocols (ATEX, CSA, VDE, IEC-Ex)
