Overview
The Schneider AS-P810-000 power supply is a primary power module designed for Modicon 984 Series PLCs and the 800 Series industrial automation platform. This unit operates on 115/230 VAC ±10% at 50/60 Hz, provides a typical 24 VDC output, and delivers up to 2 Amperes, making it essential for critical automation environments requiring stable, regulated DC power.
Key Features
- Over 85% efficiency at full load, promoting energy savings and reduced heat generation
- Ripple voltage maintained below 100 mV peak-to-peak for stable, clean power output
- Built-in protection against overloads to enhance reliability
- Overvoltage protection, short circuit protection, and thermal shutdown mechanisms
- Fixed slot mount installation type with perfect fit in the first slot of primary housing
- Passive cooling operation, simplifying design and reducing need for additional cooling components
Technical Specifications
This power supply delivers 5000 mA at 5V and 4.3V outputs while supporting a -5V output at 300 mA, with a maximum output of 7500 mA. Operating temperature range is -10°C to +60°C (14°F to 140°F), and storage temperature ranges from -20°C to +85°C (-4°F to 185°F).
Typical Applications
In manufacturing environments, the AS-P810-000 power supply is pivotal for ensuring uninterrupted operation of PLCs that control various processes, including assembly lines, material handling, and packaging systems. The compact and rugged design allows for installation in tight spaces without compromising performance, with durable construction ensuring long-term reliability even in demanding conditions.
Compatibility & Replacements
Compatible With
- Modicon 984 Series PLC platform
- Schneider Electric 800 Series industrial automation systems
- Local and remote I/O drops
Replaces / Drop-In Replacement For
The AS-P810-000 is the primary power supply for Modicon 984 Series controllers. Verify compatibility with your system integrator before ordering, as replacement models vary by specific platform revision.
Works With
- Modicon 984 controllers and I/O chassis
- Schneider Automation legacy platforms
- Industrial control systems requiring 24 VDC regulated power
