Overview
The Schmersal 101190052 BPS 36-1 is a magnetic safety actuator engineered for integration with Schmersal BNS36 safety switches. This actuator positions both the sensor and actuator on a single mounting plane, delivering reliable performance in industrial safety systems where synchronized actuation is critical. The unit is new in box and available for immediate shipment from PLC Machinery.
Key Features
- Magnetic design for dependable safety switch activation
- Straight-style configuration positions actuator and sensor on the same mounting level
- Compatible with Schmersal BNS36 safety switch series
- Compact footprint suitable for confined spaces
- Standard construction for harsh industrial environments
Technical Specifications
- Actuator Type: Magnetic, Straight
- Model: BPS 36-1
- Part Number: 101190052
- Weight: 0.50 lbs
- Dimensions: 3-1/2″ × 1″ × 1/2″
- Mounting Holes: 2 oblong, 3/8″ × 3/16″
- Classification: Safety Sensor Actuator
Typical Applications
- Machinery guarding and safety interlock systems
- Rotating equipment safety applications
- Industrial presses and automated assembly lines
- Door and gate safety switches
- Equipment access point monitoring
Compatibility & Replacements
Compatible With
- Schmersal BNS36 safety switch series
- Standard DIN rail safety control systems
- Industrial machinery safety applications requiring dual-channel logic
Replaces / Drop-In Replacement For
- BPS 36-1 (original Schmersal part)
- Other magnetic actuators for BNS36 systems (verify compatibility with your system integrator)
Works With
- Schmersal safety switch controllers and logic modules
- Standard PLC safety relay modules
- Industrial control systems with 24 VDC safety circuits
