Overview
The Rexroth FCS01.1E-W0015-A-04-NNBV is a sophisticated frequency converter from the IndraDrive FC series, manufactured by Bosch Rexroth Indramat for demanding industrial motion control applications. This compact drive handles single and multi-axis servo systems with sensorless vector control capability, making it suitable for assembly lines, material handling, and precision positioning tasks. The unit operates with three-phase AC mains (380–480V, 50/60 Hz) and includes integrated thermal management via onboard fan cooling.
Key Features
- Sensorless Vector Control: Enables independent motor parameter identification without external feedback sensors.
- Compact Design: Dimensions of 226mm x 73mm x 153mm for efficient DIN rail mounting in control cabinets.
- High Overload Capacity: 200% overload capacity allows sustained peak performance during transient loads.
- Integrated Cooling: Onboard fan cools the converter for thermal stability in tight enclosures.
- Self-Diagnostic LEDs: Four-line display unit and two LED status indicators provide real-time operational feedback.
- Configurable Pulse Frequency: Pulse frequency adjustable from 3 to 16 kilohertz for optimized motor control.
Technical Specifications
The FCS01.1E-W0015-A-04-NNBV meets international standards for industrial automation and operates reliably across a wide temperature envelope. Operating temperature range is 0°C to +40°C, with storage capability from -25 to +70 degrees Celsius. The converter features IP20 protection class, blocking intrusion from foreign materials exceeding +50mm in diameter.
Typical Applications
- Assembly Systems: Precise synchronization of multiple servo axes in electronics and automotive manufacturing.
- Material Handling: Coordinated motion in robotic palletizers, conveyor systems, and automated storage/retrieval systems.
- Food Processing: Speed and position control in filling machines, packaging equipment, and production conveyors.
- CNC Machinery: Spindle drive and axis control for precision machining operations.
Compatibility & Replacements
Compatible With
- Three-phase AC motors (380V–480V, 50/60 Hz, 4-pole standard design)
- Rexroth IndraDrive motion control systems
- External braking resistors for dynamic deceleration (FLR01.1N series recommended)
- DIN 35mm rail mounting in standard control cabinets
- Serial communication (RS232, RS485) interfaces
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The FCS01.1E-W0015-A-04-NNBV is part of the IndraDrive FC modular family and may replace earlier FCS01 variants depending on controller firmware and parameterization support.
Works With
- Rexroth Drive & Control engineering software
- Comfort Control Panel (optional keypad accessory)
- Analog/digital I/O signals for process integration
- Rexroth servo motors (MHD and MSM series optimized for this drive)
- Industrial Ethernet and PROFINET connectivity (where supported by application)
