Overview
The Pulnix PS-510 is a passive infrared (PIR) door sensor engineered for threshold-level motion detection in access control and security systems. Unlike active infrared systems that emit light beams, the PS-510 detects infrared radiation emitted by objects—particularly the thermal differential between a human body and the surrounding environment. This passive detection approach makes it ideal for doorway applications where reliable, contact-free triggering is required.
Key Features
- Passive infrared detection—no emitter beam required
- Threshold-focused detection pattern optimized for doorway coverage
- Field-selectable options and adjustments for customized response
- Suitable for door strike release and automatic door operation
- Compatible with alarm system shunting and access control networks
- Compact white housing for discrete installation
Technical Specifications
Due to limited availability of detailed specifications in current distributor catalogs, the following information is based on general PS-510 sensor design standards. For exact electrical ratings, operating temperature range, and dimensional data, consult the manufacturer’s datasheet or contact your supplier:
- Detection Technology: Passive Infrared (PIR)
- Application: Doorway threshold motion detection
- Housing Color: White
- Function: Door sensor for access control and security
- Configuration: Field-selectable options available
- Compatible with: Access control systems, door automation, alarm integration
Typical Applications
- Access Control: Automatic triggering of door strikes and electronic locks on authorized exit
- Automatic Doors: Request-to-exit (RTE) sensor for hands-free door operation
- Security Systems: Alarm system shunting and integration with existing security networks
- Building Automation: Motion-triggered lighting and HVAC control at access points
Compatibility & Replacements
Compatible With
- Magnetic lock (Maglocks) door release systems
- Electric strike door systems
- Access control panels and controllers
- Burglar and fire alarm systems with sensor integration
- Automatic door operators (sliding, swing)
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. Pulnix sensor models may have cross-compatibility with Takex brand sensors in the same series.
Works With
- Access control platforms using low-voltage door sensor inputs
- Conventional (non-networked) alarm system zones
- Building management systems with relay-based motion inputs
- Stand-alone door automation controllers
