Overview
The Red Lion PSDR060W is a single-output AC-DC switching power supply designed for industrial automation and control systems. This compact DIN rail-mounted unit delivers reliable 24VDC power at 2.5A (60W maximum) from a universal 100-240VAC input, making it suitable for global applications. The PSDR060W is built for dependable operation in sensor arrays, PLC systems, HMI panels, and stack light control circuits where consistent low-voltage power is critical.
Key Features
- 60W output power capacity with 24VDC, 2.5A continuous rating
- Universal 100-240VAC input accommodates global voltage standards
- Compact DIN rail design (35mm) for space-efficient panel mounting
- Lightweight construction (approximately 230 grams) for easy installation
- RoHS compliant and ITE approved for industrial use
- Wide operating temperature range: -10°C to +60°C
Technical Specifications
- Input Voltage: 100-240VAC, 50-60Hz
- Output Voltage: 24VDC
- Output Current: 2.5A (maximum)
- Power Rating: 60W
- Number of Outputs: 1
- Mounting: 35mm DIN rail
- Operating Temperature: -10°C to +60°C
- Weight: Approximately 230 grams (0.5 lbs)
- Approvals: ITE, RoHS Compliant
- Type: Switching Mode Power Supply
Typical Applications
The PSDR060W is commonly deployed in industrial control cabinets, machinery automation, and distributed I/O systems. Typical uses include powering 24VDC field instruments, PLC input/output modules, solenoid coils, indicator lights, and sensor circuits. Its universal input voltage makes it especially valuable in multi-voltage facilities and international installations where standardized 24VDC power distribution is preferred.
Compatibility & Replacements
Compatible With
- Allen-Bradley PLCs and I/O modules requiring 24VDC auxiliary power
- Siemens S7-1200 and S7-1500 control systems
- Mitsubishi FX and Q series PLC power requirements
- Omron CJ and CP series programmable controllers
- Standard 24VDC sensor and solenoid loads
- Industrial Ethernet switches and gateways (24VDC input)
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The PSDR060W is part of Red Lion’s PSDR series; consult the original equipment documentation to confirm direct replacement capability.
Works With
- Standard 35mm DIN rail panel mounting systems
- Industrial control cabinet installations
- Field wiring harnesses and terminal blocks rated for 24VDC
- Any IEC 61131-3 compliant automation controller requiring 24VDC auxiliary supply
