Overview
The Potter & Brumfield 27E892 is an 11-pin general-purpose relay socket engineered for industrial and commercial control systems. This DIN rail-mountable socket delivers 10A continuous current handling at 300VAC, making it ideal for general-purpose relay installations in control panels and electrical enclosures. Built with a polyamide body and tin-plated spring brass contacts, the 27E892 provides secure, long-lasting performance and easy maintenance access.
Key Features
- 11-pin octal configuration for quick, standardized installation
- Snap-on DIN rail mounting for fast panel integration
- Screw-type terminals for secure, tool-free wire connections
- Hold-down springs to secure relay in place during operation
- UL E59244 and CSA LR15734 certified for industrial use
- RoHS compliant polyamide and brass construction
Technical Specifications
- Manufacturer: TE Connectivity (Potter & Brumfield)
- Part Number: 27E892
- Alternative Part Number: 2-1419106-4
- Pin Configuration: 11-pin Octal
- Current Rating: 10A
- Voltage Rating: 300VAC
- Mounting Type: DIN Rail (Snap-on)
- Terminal Type: Screw
- Housing Material: Polyamide
- Contacts: Tin-plated spring brass
- Dimensions: 2.332 × 2.035 × 0.770 inches
- Certifications: UL E59244, CSA LR15734
- RoHS Compliant: Yes
- Quantity: Lot of 2
Typical Applications
The 27E892 relay socket is widely used in:
- Industrial control panels and machinery electrical systems
- HVAC and refrigeration control circuits
- Motor starter and contactor installations
- General-purpose 300VAC industrial relay circuits
- OEM equipment and retrofit installations requiring standard relay sockets
Compatibility & Replacements
Compatible With
- KRP series relays (Potter & Brumfield)
- KRPA series relays (Potter & Brumfield)
- Standard 11-pin octal relay cartridges
- DIN rail-based control systems
Replaces / Drop-In Replacement For
- Potter & Brumfield 27E892 (original specification)
- TE Connectivity part 2-1419106-4 (equivalent cross-reference)
Works With
- Potter & Brumfield KRP and KRPA general-purpose relays
- Standard DIN 43650 rail mounting systems
- Industrial control and automation platforms using 11-pin relay cartridges
- 20C318 relay clips and mounting accessories
